Generac Power Systems Stationary emergency generator Owner's Manual page 103

1 0F9677 1
0G0056 1
0G0959 1
0G1155 1
0G1931 1
0G2101 1
0G3734 1
0G6562 1
0G6564 1
2 0F9664 1
0G0057 1
0G0058 1
0G0059 1
0G0183 1
0G0184 1
0G1932 1
0G2098 1
0G2099 1
0G2100 1
0G3736 1
0G3737 1
0G3738 1
0G6104 1
0G6563 1
0G6565 1
0G6566 1
0G6567 1
0H0201 1
0H1299 1
0H1300 1
0H1301 1
3 0C9708 REF
4 SEE ENGINE EV REF
5 SEE ENGINE EV REF
6 0F5767B 1
7 0E5706 1
8 0F7874 1
0F7874A 1
9 0G0587 1
10 038150 4
11 023454 1
12 077043E 1
13 04576100BU 4
14 052646 4
15 043123 4
16 051779 4
17 0A2601 1
18 072879 1
19 0F8408 4
20 046526 4
21 0C3992 4
22 022264 4
23 * 047248 1
24 * 070892 1
25 0G0588 1
26 077043A 1
27 056326 1
* ROTOR REPLACEMENT PARTS
ROTOR-2390-45KD1 CPL
ROTOR-2390-35KD1 CPL
ROTOR-2390-45KD1 CPL (G2)
ROTOR-2390-35KD1 CPL (G2)
ROTOR 25KW 3PH DIRECT 390 1800
ROTOR 25KW 1PH DIRECT 390 1800
RTR-2390-60KD2 CPL
RTR 390 35AD1 CPL
RTR 390 35KD1 CPL
STATOR-390 45K 2P 1PH DIRECT
STATOR-2390-35AD1 CPL
STATOR-2390-35KD1 CPL
STATOR-2390-35GD1 CPL
STATOR-2309-45KW 2P 3PH 208V
STATOR-2309-45-KD1 CPL
ASSY STR 390 25GD3 CPL
ASSY STR 390 25AD1 CPL
ASSY STR 390 25KD3 CPL
ASSY STR 390 25JD3 CPL
ASSY STR 2390 60AD2 CPL
ASSY STR 390 60KW 2P 3PH 208V
ASSY STR 390 60KW 2P 3PH 480V
STR-2390--45JD1 CPL
STR 390 35AD1 CPL
STR 390 35GD1 CPL
STR 390 35KD1 CPL
STR 390 35JD1 CPL
STR-2390--60JD2 CPL
ASSY STR 390 36AD1 CPL
ASSY STR 390 36JD1 CPL
ASSY STR 390 36 GD1 CPL
INSTR HYPOT TEST (NOT SHOWN)
ENGINE ADAPTER
FLEXPLATE
ASSY FLYWHEEL CPL W/40MM FAN B
REAR BEARING CARRIER 390/DRCT
ASSY BRUSH HOLDER 390/HSB
ASSY BRUSH HOLDER 390/HSB
GUARD REAR BEARING CARRIER
WASHER FLAT #8 ZINC
KEY WOODRUFF #E
CONDUIT FLEX 1.0" ID (35" LG)
STUD M14-2.0 570 G5 ZINC
WASHER FLAT M14
WASHER LOCK M14
NUT HEX M14-2.0 G8 YEL CHR
SCREW HHC M16-2.0 X 45 G8.8
SPACER .69 X 2.75 X .37 ST/ZNC
SCREW HHC M10-1.50 X 16 G10.9
WASHER LOCK M10
SCREW HHTT M4-0.7 X 16 BP
WASHER LOCK #8-M4
BALL BEARING-45 MM
SLIP RING MACHINED
GUARD REAR BEARING CARRIER
CONDUIT FLEX .38" ID (60")
TRIM VINYL BLACK 1/8GP (16.5"LG)
