Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2000 Porter-Cable Corporation
ESPAÑOL: PÁGINA 15
FRANÇAISE : PAGE 31
Double Insulated
Routers
MODEL 7536
Consisting of:
MODEL 75361 Base
MODEL 75362 Motor
MODEL 7537
Consisting of:
MODEL 75371 Base
MODEL 75372 Motor
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
Part No. 900314-0010
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Porter-Cable 7536
Summary of Contents for Porter-Cable 7536
- Page 1 MODEL 7537 Consisting of: MODEL 75371 Base MODEL 75372 Motor IMPORTANT To learn more about Porter-Cable Please make certain that the person who is visit our website at: to use this equipment carefully reads and understands these instructions before http://www.porter-cable.com starting operations.
-
Page 2: Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter- Cable and we have advised you. - Page 3 DRESS PROPERLY. Do not wear loose clothing or jewelry. Loose clothing, draw strings and jewelry can be caught in moving parts. Rubber gloves and non-skid footwear are recommended when working outdoors. Wear protective hair covering to contain long hair. USE SAFETY GLASSES. Wear safety glasses or goggles while operating power tools.
-
Page 4: Replacement Parts
When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 5: Operating Instructions
14-16 16-18 18-20 OPERATING INSTRUCTIONS FOREWORD These Porter-Cable routers are designed for continuous, rugged operation to handle the most demanding production applications. SELECTING THE BIT These routers accommodate bits with " diameter shanks that are installed directly into the power unit collet. Collets are available that will allow the use of bits having "... - Page 6 3. Clean and insert shank of bit into collet until shank bottoms. Then back it out approximately ". Lay motor unit on its side on bench with the collet pointing AWAY from you. Place one wrench on flats on chuck with the opposite end of the wrench resting on the bench to your left, Fig.
-
Page 7: Adjusting Depth Of Cut
Fig. 4 ASSEMBLING THE MOTOR IN THE ROUTER BASE EQUIPPED WITH TWO HANDLES CAUTION: DISCONNECT MOTOR FROM POWER SOURCE. Loosen the clamp screw (A) Fig. 1 to allow the power unit to be set in the base unit. Insert motor unit into base aligning lower pin (B) with groove in base. Rotate motor unit CLOCKWISE into base until upper guide pins are rigidly set in the groove of the base. - Page 8 Fig. 5 Turn motor unit (F) Fig. 5 CLOCKWISE until bit touches the wood surface. Tighten clamp screw (A) Fig. 5. Rotate depth adjusting ring (B) Fig. 5 until the zero-line (C) is opposite the index line (D) on the housing. Loosen clamp screw (A) Fig.
-
Page 9: Connecting To Power Source
CONNECTING TO POWER SOURCE CAUTION: Before connecting router to power source ALWAYS MAKE SURE SWITCH IS IN THE “OFF” POSITION. Also check that the power circuit is the same as that shown on specification plate of the router. STARTING AND STOPPING THE MOTOR CAUTION: Before starting the router make sure bit is clear of work piece and foreign objects. -
Page 10: Using The Router
USING THE ROUTER IMPORTANT: Before using your router, consider the kind and total amount of material to be removed. Depending on the material, it may be necessary to make more than one cut to avoid overloading the motor. Before beginning the cut on the actual workpiece, it is advisable to make a sample cut on a piece of scrap lumber. - Page 11 WARNING: Avoid “Climb-Cutting” (cutting in direction opposite that shown in Fig. 8), “Climb-Cutting” increases the chance for loss of control resulting in possible personal injury. When “Climb-Cutting” is required (backing around a corner), exercise extreme caution to maintain control of router. The speed and depth of cut will depend largely on the type of material being worked upon.
-
Page 12: Maintenance
BRUSH INSPECTION At approximately 100 hours of use, take or send your tool to your nearest Authorized Porter-Cable Service Station to be thoroughly cleaned and inspected; worn parts replaced, when necessary; relubricated with fresh lubricant, if required; reassembled with new brushes; and performance tested. - Page 13 ACCESSORIES The testing of these tools has been accomplished with the use of the following accessories ONLY. For safest operation, it is recommended that ONLY these accessories be used with this product. WARNING: Since accessories other than those listed have not been tested with this product, use of such accessories could be hazardous.
- Page 14 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 15 Porter-Cable products should be obtained by contacting any Porter-Cable Distributor, Authorized Service Center, or Porter-Cable Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable Factory Service Center.
