Overview
The System 5 control surface consists of a number of control surface modules. These modules
are described below. Typically, each connects to the system via a network cable. Each console
must include one CM401T Master Module and at least one CM408T Eight-Fader Module.
• CM401T: Master control module with configuration interface.
• CM402T: Expanded channel module with eight faders.
• CM403: Dual joystick and film monitor panel.
• CM408T: Eight-fader module.
• CM411: VGA/DVI input module with optional dual joysticks.
