Table of Motherboard Components
LABEL
Socket AM2 for AMD Athlon
1.CPU Socket
Althlon
240-pin DDR2 SDRAM slots
2.DIMM1~2
Standard 24-pin ATX power connector
3.ATX_POWER
Floppy disk drive connector
4.FDD
5.IDE1 Primary IDE connector
Wake On LAN Connector
6.WOL1*
Serial ATA connectors
7.SATA1~4
8.JLPC1 TPM header
Infrared header
9.IRDA*
Clear CMOS jumper
10.CLR_CMOS
11.PANEL1 Front panel switch/LED header
12.USB3~5 Front Panel USB headers
Onboard serial port header
13.COM1
Analog audio input connector
14.CD_IN1
15.AUDIO1 Front panel audio header
SPDIF out header
16.SPDIFO
32-bit add-on card slots
17.PCI1~2
18.PCIEX16 PCI Express x16 slot for graphics interface
PCI Express x1slot
19.PCIEX1
TV-out header
20.TV_OUT1
System cooling fan connector
21.SYS_FAN
22.ATX12V Auxiliary 4-pin power connector
CPU cooling fan connector
23.CPU_FAN
* Stands for optional components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
Introducing the Motherboard
COMPONENTS
™
64 X2 Dual-Core/
™ ™
64/Sempron processors
5
