Product features may vary from the picture above.
PICK-UP TRUCK
Owner's Manual
with Assembly Instructions
Please read this manual and save it with your original sales receipt.
For Model 74210
Tools needed for assembly: Phillips Screwdriver, Slotted Screwdriver, Hammer, and Safety Scissors.
Use only with Power Wheels
®
Type H 6 Volt (9.5 Amp./hr. - included or 12 Amp./hr. - not included) Batteries,
Power Wheels
®
30 Amp Fuses (included) and Power Wheels
®
Type H 12 Volt Charger (included).
CAUTION
ELECTRIC TOY: Not recommended for children under 3 years of age.
As with all electric products, precautions should be observed during
handling and use to prevent electric shock.
Advertisement
Table of Contents
Related Manuals for Power Wheels FORD 74210
Summary of Contents for Power Wheels FORD 74210
- Page 1 ® Product features may vary from the picture above. PICK-UP TRUCK Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sales receipt. For Model 74210 Tools needed for assembly: Phillips Screwdriver, Slotted Screwdriver, Hammer, and Safety Scissors. Use only with Power Wheels ®...
-
Page 2: Table Of Contents
Important Information ..............2 Warnings . -
Page 3: Warnings
• Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the batteries, or help in assembly of the vehicle. -
Page 4: Parts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 5 Parts #8 x 1" Screw – 12 Knob #6 x " Screw – 2 30 Amp Fuse – 3* .354 Cap Nut – 3* #6 x " Screw – 2 * For your convenience, an extra 30 amp fuse All Shown Actual Size and .354 cap nut have been included.
-
Page 6: Parts Diagram
Hood Microphone Steering Column Steering Wheel Steering Wheel Cap Cap Nut – 2 Dash Cover Knob Parts Diagram Parts Seat Tailgate Left Taillight Right Taillight Vehicle Body Grille 6 Volt Battery – 2 30 Amp Fuse – 2 Battery Retainer Seat Belt Straps - 2 12 Volt Charger Not Shown: Label Sheet... -
Page 7: Battery Charging
• The batteries must be handled by adults only. The batteries are heavy and contain sulfuric acid (electrolyte). Dropping the batteries could result in serious injury. • Never allow children to charge the batteries. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the batteries. -
Page 8: Battery Charging
30 Amp Fuse • If you are charging the batteries for the first time, insert a 30 amp fuse into each battery before charging. Note: The top of the fuse will not be flush with the top of the battery when properly installed. •... -
Page 9: Assembly
Tabs • Position the dash cover as shown. Make sure the three tabs are at the top. • Fit the key into the hole in the right side of the dash cover. • Fit the knob into the hole to the left of the key. •... - Page 10 Steering Column Bottom View • Fit the curved end of the steering column into the hole in the front axle. Please Note: You may need to straighten the vehicle tires and rotate the steering column to fit it into the hole in the front axle.
- Page 11 Seat Belt Straps Second T-tab Seat • Make sure the two seat belt straps are fastened together. If they are not fastened together, connect the fasteners to form one seat belt. • Insert the T-tab at one end of the seat belt through the slot in one arm of the seat.
- Page 12 Inner Holes Front Bumper • Insert a #8 x 1" screw into each of the two inner screw holes in the top of the front bumper. • Tighten the screws with a Phillips screwdriver. Do not over-tighten. • Insert a #8 x 1" screw into each of the two outer screw holes in the top of the rear bumper.
- Page 13 Slots Grille Opening Grille Opening Side Tab Tabs Grille • Face the front of the vehicle. • Insert the two tabs at the top of the grille into the slots in the front of the vehicle body. • Press firmly to snap the tabs into the slots. •...
-
Page 14: Label Decoration
Proper label application will help to keep the labels look- ing their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. -
Page 15: Battery Installation
Important Note: Use only Power Wheels ies with Power Wheels ® 30 amp fuses installed. Use of any other batteries or fuses will damage your vehicle. Make sure that you charge the batteries for at least 18 hours using the enclosed Power Wheels ®... -
Page 16: Battery Care And Disposal
Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician. If acid is internally ingested, give water, milk of magne- sia or egg whites immediately. -
Page 17: Rules For Safe Driving
WARNING • Adult supervision is required. Children do not have the judgement necessary to avoid many accidents. Be sure that children oper- ating this vehicle can do so safely and that they are supervised at all times. • Never use near steps, driveways, steep inclines, roadways, alleys, swimming pool areas or other bodies of water. -
Page 18: How To Operate Your Vehicle
Beginner Use - Low Speed Drive As assembled, your vehicle is ready to roll in low speed mph, maximum). • Make sure the shifter is in the low speed ( position • Press down on the foot pedal ward at a maximum of 2 •... -
Page 19: Caring For Your Vehicle
How to Operate Your Vehicle Advanced Use - High Speed Drive Disconnecting the High Speed Lock-Out Shifter Box • Before you disconnect the high speed lock-out, make sure your child knows how to steer, how to start and stop the vehicle and knows the rules for safe driving. When the high speed lock-out is disconnected, the vehicle can be driven forward in low speed (2 high speed (5 mph, maximum). -
Page 20: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels the Authorized Service Center list beginning on page 24. -
Page 21: Problems And Solutions Guide
Problems and Solutions Guide Problem Vehicle was running but Loose wire or loose connectors suddenly stopped Wrong type or improperly installed fuse Blown fuses Short run time (Less than Undercharged batteries 1 - 3 hours per charge) Overcharged batteries Batteries are old and will not accept full charge Wrong type or improperly installed fuse Driving conditions are too stressful... - Page 22 Problems and Solutions Guide Problem Vehicle runs sluggishly Undercharged batteries Batteries need charging Wrong type or improperly installed fuses Batteries are old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful Vehicle runs in low speed, but High speed lock-out not disconnected does not run in high speed (Please Note: The vehicle is...
-
Page 23: Problem Possible Cause
Problems and Solutions Guide Problem Vehicle constantly blows fuses Wrong type of fuse used Child is switching between speeds or between forward and reverse without stopping. Loud clacking or grinding Broken gears noise from a motor-gearbox Charger gets warm during use It is normal for some chargers to get warm during use and is not reason for concern. -
Page 24: Statement Of Limited Warranty
Statement of Limited Warranty 90-day limited warranty for the Power Wheels ® Ride-On Toy Vehicle A 6-month battery warranty applying only to those 6 volt batteries which were included by Power Wheels , with the Power Wheels ® vehicle when originally purchased. This limited warranty covers the Power Wheels ride-on vehicle and the 6 volt batteries, purchased from Power Wheels... - Page 25 ALABAMA BIRMINGHAM - Frigid Service & Sales, 701 Graymont Ave. North, 35203, (205) 323-5831 BIRMINGHAM - Frigid Service & Sales, 1861 Centerpoint Rd., 35215, (205) 853-3952 BIRMINGHAM (HOMEWOOD) - D & R Appliance Company, 154 West Valley Ave., 35209, (205) 942-3959 CULLMAN - Robert G.
- Page 26 ALABAMA BIRMINGHAM - Frigid Service & Sales, 701 Graymont Ave. North, 35203, (205) 323-5831 BIRMINGHAM - Frigid Service & Sales, 1861 Centerpoint Rd., 35215, (205) 853-3952 BIRMINGHAM (HOMEWOOD) - D & R Appliance Company, 154 West Valley Ave., 35209, (205) 942-3959 CULLMAN - Robert G.
- Page 27 ALABAMA BIRMINGHAM - Frigid Service & Sales, 701 Graymont Ave. North, 35203, (205) 323-5831 BIRMINGHAM - Frigid Service & Sales, 1861 Centerpoint Rd., 35215, (205) 853-3952 BIRMINGHAM (HOMEWOOD) - D & R Appliance Company, 154 West Valley Ave., 35209, (205) 942-3959 CULLMAN - Robert G.
- Page 28 FORD, F-150 and associated trademarks used under license from Ford Motor Company. Goodyear (and winged foot design) and Wrangler (for tires) are trademarks of The Goodyear Tire & Rubber Company, used with permission. ©1997 Fisher-Price, Inc., East Aurora, New York 14052 - All Rights Reserved Printed in the U.S.A. 74210 1...
