111-1471 (C)
29/8/08
(English Version)
CODE
FROM SERIAL NO:
560F
280000001
561F
280000001
ISSUE 29.08.08
12:56 pm
Page 1.1
Harrier 56
CODES
560F
Auto Drive
(Variable Speed)
OWNER'S HANDBOOK
561F
Auto Drive
(Variable Speed)
(Electric Start)
PART NUMBER: 111-1471 (C)

Advertisement

Table of Contents
loading

Related Manuals for Hayter Harrier 56 560F

Summary of Contents for Hayter Harrier 56 560F

  • Page 1 111-1471 (C) 29/8/08 12:56 pm Page 1.1 Harrier 56 CODES 560F 561F Auto Drive Auto Drive (Variable Speed) (Variable Speed) (Electric Start) OWNER'S HANDBOOK (English Version) PART NUMBER: 111-1471 (C) CODE FROM SERIAL NO: 560F 280000001 561F 280000001 ISSUE 29.08.08...

  • Page 2: Specifications

    111-1471 (C) 29/8/08 12:56 pm Page 1.2 MAIN FEATURES /SPECIFICATIONS Main Features Spark Plug Lead. Engine Cover. Air Cleaner. Fuel Filler Cap. Oil Filler Cap and Dipstick. Serial No.Label. Handlebar Securing Knob. Engine Start-Grip. Throttle Control. Key ( 561 only ). Engine Stop Lever.
  • Page 3 111-1471 (C) 29/8/08 12:56 pm Page 1.3 1st Year (12 months) 1st Year (12 months) Owner’s Name: We certify that this service has been carried out by an Authorised Hayter Serial Number: Service Dealer Date: Date: Note for dealer: Please retain this voucher for your records. 2nd Year (24 months) 2nd Year (24 months) Owner’s Name:...
  • Page 4 111-1471 (C) 29/8/08 12:56 pm Page 1.4...

  • Page 5: Table Of Contents

    111-1471 (C) 29/8/08 12:56 pm Page 1.5 CONTENTS 1.2 Main Features/Specifications 1.23 - 1.31 Mower Maintenance 1.5 Contents 1.23 - Engine 1.23 - Throttle Cable Adjustment 1.6 Introduction 1.23 - Carburettor Adjustments 1.24 - Oil Service 1.7 Warranty 1.24 - Air Cleaner Service 1.25 - Spark Plug Service 1.8 - 1.11 Safety Precautions...

  • Page 6: Introduction

    Any arbitrary modifications carried out to this machine may relieve Hayter Limited of liability for any resulting damage or injury. Hayter mowers are robustly constructed and designed for efficient economical performance under normal mowing conditions. Correct operation and maintenance will ensure a long and satisfactory service life.

  • Page 7: Warranty

    111-1471 (C) 29/8/08 12:56 pm Page 1.7 WARRANTY LIMITED WARRANTY Hayter Limited warrants to the original user/purchaser that this unit shall be free from defects in material and workmanship under normal use and service for a period of three years from the date of purchase.

  • Page 8: 1.11 Safety Precautions

    111-1471 (C) 29/8/08 12:56 pm Page 1.8 SAFETY PRECAUTIONS Safety Alert Symbol This safety alert symbol indicates important safety messages. When you see this symbol be alert to the possibility of injury. Carefully read the following and inform others. Your mower is perfectly safe if used correctly. Failure to observe the following precautions may result in serious injury.

  • Page 9: Operation

    111-1471 (C) 29/8/08 12:56 pm Page 1.9 SAFETY PRECAUTIONS Preparation Continued - Always use fresh fuel. Stale fuel can block the carburettor and cause leakage. - Replace fuel tank and oil tank caps securely. A damaged cutterblade or loose fixing bolt are major hazards. Before use, always visually inspect the cutting mechanism to ensure that it is in good condition.

  • Page 10: 1.11 - Maintenance And Storage 1.26

    111-1471 (C) 29/8/08 12:56 pm Page 1.10 SAFETY PRECAUTIONS Operation Continued Do not tilt the mower when starting the engine. Do not put hands or feet near or under rotating parts. Never pick up or carry the mower while the engine is running. Never lift the rear deflector while the engine is running.

  • Page 11: Safety Symbols

    111-1471 (C) 29/8/08 12:56 pm Page 1.11 SAFETY PRECAUTIONS Maintenance & Storage Continued Allow the engine to cool before storing in any enclosure. To reduce the fire hazard, keep the engine and the surrounding deck area free of grass, leaves, or excessive grease. Check the rear deflector and grassbag frequently for wear or deterioration.

  • Page 12: Assembling The Mower

    111-1471 (C) 29/8/08 12:56 pm Page 1.12 ASSEMBLING THE MOWER Delivery Checklist Remove the mower from the packaging and check that the following items have been supplied correctly. If any items are missing contact, your local Hayter dealer. 1. Engine Handbook. 3.

  • Page 13: Before Starting The Mower

    111-1471 (C) 29/8/08 12:56 pm Page 1.13 BEFORE STARTING MOWER Prevent Engine Damage To prevent engine damage the engine is shipped without oil or petrol. The engine must be filled with the correct grade of oil and petrol before starting the engine. Oil Type Always use high quality detergent oil classified SAE 30 oil.

  • Page 14: 1.19 Operating The Mower

    111-1471 (C) 29/8/08 12:56 pm Page 1.14 OPERATING THE MOWER Controls Operate all control levers several times and ensure that the cables move freely. Check that the engine stop and ground drive clutch levers return freely to their rest position when released. Whilst operating the engine throttle mechanism slight resistance should be felt when moving the lever to the ‘choke’...

  • Page 15: Electric Start 1.39

    111-1471 (C) 29/8/08 12:56 pm Page 1.15 OPERATING MOWER Step 3 Allow the engine to warm up and move the throttle lever to the ‘fast’ position after starting a cold engine. To prevent damage never pull the engine start grip when the engine is running.

  • Page 16: Reverse Travel

    111-1471 (C) 29/8/08 12:56 pm Page 1.16 OPERATING THE MOWER Reverse Travel Hold and pull against the handlebar with both hands to reverse the mower. Turning To make a wide turn steer the mower with the handlebar in the direction required. To make a tight turn release the ground drive clutch lever, apply downward pressure on the handlebar to raise the front wheels just above ground level and steer in the required direction.

  • Page 17: Slopes

    111-1471 (C) 29/8/08 12:56 pm Page 1.17 OPERATING MOWER Slopes To prevent engine damage do not use the mower on slopes greater than 20 degrees. Height of Cut To adjust the height of cut: Grip the lever and pull sideways to disengage it from the locking notch, then push forwards to lower or pull backwards to raise the height of cut.

  • Page 18: Before Mowing

    111-1471 (C) 29/8/08 12:56 pm Page 1.18 OPERATING THE MOWER Before Mowing To prevent accidents, thoroughly inspect the area and remove all objects which when contacted by the mower cutterblade could become dangerous projectiles. Inspect the area for hidden obstruc- tions which when contacted by the cutterblade could risk health and safety or result in damage to the mower.

  • Page 19: Heavy Growth

    111-1471 (C) 29/8/08 12:56 pm Page 1.19 OPERATING MOWER Heavy Growth Areas of heavy growth should be mown without collecting the clip- pings. If collection is required, first mow the area without the grassbag at the maximum height of cut setting. Allow the grass clippings to dry out and then mow the area at the maximum height of cut setting with the grassbag fitted.

  • Page 20: Lawn Care Calendar

    111-1471 (C) 29/8/08 12:56 pm Page 1.20 LAWN CARE CALENDAR To be used as a guide only. January There is very little work to do this month apart from brushing away leaves. Keep off the grass if frozen or waterlogged. February Rake the grass thoroughly.

  • Page 21: Lawn Care

    111-1471 (C) 29/8/08 12:56 pm Page 1.21 LAWN CARE CALENDAR August Keep mowing regularly and watering as necessary. Fill any cracks caused by drought with a mixture of sharp sand and soil. In dry weather conditions leave the grass longer to help retain ground mois- ture.

  • Page 22: Maintenance Schedule

    111-1471 (C) 29/8/08 12:56 pm Page 1.22 MAINTENANCE SCHEDULE Follow the hourly or calendar intervals, whichever occurs first. More frequent service will be required if working for prolonged periods under dusty, dry conditions, or when airborne debris is present or after exten- sive operation cutting tall, dry grass.

  • Page 23: 1.31 Mower Maintenance - Engine

    111-1471 (C) 29/8/08 12:56 pm Page 1.23 MOWER MAINTENANCE To prevent accidents stop the engine and disconnect the spark plug lead before attempting to carry out maintenance proce- dures on the mower. Engine Air Cleaner Spark Plug / Lead Carburetor Exhaust Guard Exhaust Oil fill/Dipstick...

  • Page 24: Oil Service

    111-1471 (C) 29/8/08 12:56 pm Page 1.24 MOWER MAINTENANCE Oil Service Check the oil level daily before starting the engine and ensure that the correct oil level is maintained. Refer to-‘Before Starting the Mower’ for oil checking and filling instructions. Change the engine oil after the first 5 hours of operation and thereafter according to the ‘Maintenance Schedule’:- 1.

  • Page 25: Spark Plug Service

    111-1471 (C) 29/8/08 12:56 pm Page 1.25 MOWER MAINTENANCE Spark Plug Service Use only Briggs & Stratton spark tester (1) to check for a spark as shown in the diagram. Replace the spark plug every 100 hours or every season, whichever occurs first.

  • Page 26: Deck Housing

    111-1471 (C) 29/8/08 12:56 pm Page 1.26 MOWER MAINTENANCE Deck Housing Remove grass debris from the top and underside of the deck housing immediately after use. Fertilisers and top dressings are particularly corrosive. Thoroughly clean the mower deck immediately after use on treat- ed grass and store well away from corrosive materials.

  • Page 27: Lubrication

    111-1471 (C) 29/8/08 12:56 pm Page 1.27 MOWER MAINTENANCE Clutch Cable Adjustment Continued Fig. 2 3. If the distance between the clutch lever and handlebar is less than 60mm regulate the engagement position with the black plastic cable adjuster. Refer to Fig 1 and 2 to regain the 60mm distance. Fig.

  • Page 28: Cutterblade Removal

    111-1471 (C) 29/8/08 12:56 pm Page 1.28 MOWER MAINTENANCE Cutterblade Removal Drain the fuel by running the engine until the fuel tank is empty and the engine stops. Remove the spark plug lead and allow the engine to cool. Turn the mower on its left hand side and ensure that the air clean- er side of the engine is uppermost.

  • Page 29: Cutterblade Sharpening

    111-1471 (C) 29/8/08 12:56 pm Page 1.29 MOWER MAINTENANCE Cutterblade Sharpening A slightly worn cutterblade may be re-sharpened. Both blade edges must be sharpened equally to ensure balance. Sharpen the cutterblade 30-45 every 25 mowing hours or more frequently if conditions require. Remove the cutterblade from the mower and clean using a brush and water.

  • Page 30: Storage

    111-1471 (C) 29/8/08 12:56 pm Page 1.30 MOWER MAINTENANCE Storage To store the handlebar unscrew the 2 small securing knobs sufficient- ly to allow it to be pivoted forwards to rest against the mower. Take care to ensure that the control cables do not become snagged at the pivot point and depress the engine stop lever to prevent it being dam- aged through contact with the engine.

  • Page 31: Battery Charging

    111-1471 (C) 29/8/08 12:56 pm Page 1.31 MOWER MAINTENANCE Battery charging (561 only) - PREVENT ACCIDENTS: ALWAYS charge the battery in a well ventilated area. 14hrs NEVER charge the battery near naked flames or direct heat. ALWAYS switch off the mains electricity supply before disconnect- ing the charger from the battery.

  • Page 32: 1.33 Trouble Shooting

    111-1471 (C) 29/8/08 12:56 pm Page 1.32 TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Engine will not turn over Engine stop lever released. Operate engine stop lever. Incorrect oil level. Check oil level. Obstruction under deck. Remove obstruction. Battery discharged (561 Only) Charge battery Engine smokes Excess oil level.
  • Page 33 111-1471 (C) 29/8/08 12:56 pm Page 1.33 TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Engine vibrates excessively Mounting bolts loose. Tighten bolts Cutterblade bolt loose. Tighten bolt Cutterblade out of balance. Balance cutterblade Bent crankshaft. Consult your dealer Uneven cut Undulating ground conditions Change direction of travel Cutterblade worn Sharpen the cutterblade...

  • Page 34: Declaration Of Conformity

    111-1471 (C) 29/8/08 12:56 pm Page 1.34 DECLARATION CONFORMITY EC DECLARATION OF CONFORMITY Manufacturer: HAYTER LIMITED, Address: Spellbrook, Bishop’s Stortford, Herts. CM23 4BU. ENGLAND declare that the lawnmower: Model name: Harrier 56 Harrier 56 Autodrive V/S Autodrive E/S V/S Type: Pedestrian rotary Pedestrian rotary Model No:...
  • Page 35 111-1471 (C) 29/8/08 12:56 pm Page 1.35 1.35...
  • Page 36 111-1471 (C) 29/8/08 12:56 pm Page 1.36 UPPER MAINFRAME PARTS LIST Item No. Description Part No. Item Note NUT M6 NYLOC P TYPE 09544 BATTERY 12V HY412009 BATTERY COVER 560015 BOLT HANDLEBAR HY226024 CABLE ENGINE BRAKE 111-0997 CABLE ENGINE BRAKE 560041 CABLE GUIDE 410037...

  • Page 37: Mainframe Parts List

    111-1471 (C) 29/8/08 12:56 pm Page 1.37 UPPER MAINFRAME PARTS LIST 1.37...
  • Page 38 111-1471 (C) 29/8/08 12:56 pm Page 1.38 LOWER MAINFRAME PARTS LIST Item No. Description Part No. Item Note AXLE FRONT WELD ASSY 560008 BAR SPRING TENSION 560037 BEARING 63001-2RS 111-1276 BEARING FRONT AXLE 410069 BEARING HOUSING 111-1492 BELT VARIATOR 520 411024 BOLT UNF 3/8"x2.1/4"...
  • Page 39 111-1471 (C) 29/8/08 12:56 pm Page 1.39 LOWER MAINFRAME PARTS LIST Detail A 1.39...
  • Page 40 111-1471 (C) 29/8/08 12:56 pm Page 1.40 LOWER MAINFRAME PARTS LIST Item No. Description Part No. Item Note SHAFT ROLLER WELDED 111-1717 SHROUD-FREEWHEEL 340168 SPRING COUNTER BALANCE 410050 SPRING TORSION HOC 480132 SPRING VARIATOR HY412004 SPROCKET 10T 411011 SPROCKET 18T 111-1552 THROWPLATE 560011V...
  • Page 41 111-1471 (C) 29/8/08 12:56 pm Page 1.41 LOWER MAINFRAME PARTS LIST Detail A 1.41...
  • Page 42 111-1471 (C) 29/8/08 12:56 pm Page 1.42 NOTES 1.42...
  • Page 43 111-1471 (C) 29/8/08 12:56 pm Page 1.43 NOTES 1.43...

  • Page 44: Engine

    111-1471 (C) 29/8/08 12:56 pm Page 1.44 CUSTOMER INFORMATION /NOTES Serial No: Engine:- Engine Type:- Series 825 (560F) Briggs & Stratton Engine:- Engine Type:- Series 825 (561F) Briggs & Stratton Date of Sale:- Your Local Dealer:- Notes:- 1.44...
