Grizzly H8120 Instruction Sheet

EYE INJURY HAZARD!
Always wear safety glasses
when using this tool to
prevent serious personal
injury.
Always wear respirator when
Always disconnect tool from
air to prevent unexpected
operation during service.
DO NOT EXCEED 120 PSI!
Personal
occur.
Product Information
• 10,000 RPM
• Requires 90 PSI
• Air Consumption 2.8–4.5 CFM @ 90 PSI
• Requires 6" hook and loop sanding disc with
6-hole pattern
• ⁄ " NPT female air inlet
1
4
• ⁄ " (ID) dust collection hose
3
4
• Weighs 2.53 lbs.
Inventory
A. Orbital Sander ..............................................1
B. Dust Collection Hose . ...................................1
C. Dust Collection Bag . .....................................1
D. Wrench .........................................................1
E. Pneumatic Tool Oil Bottle . ............................1
F. / " NPT Male Plug .......................................1
1
4
COPyRIgHT © JANUARy, 2007 By gRIzzly INDUSTRIAl, INC. RevISeD MAy, 2009 (TR)
WARNINg: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROvAL OF gRIZZLY INDUSTRIAL, INC.
DUST HAZARD!
using this tool.
INJURY HAZARD!
injury could
#Bl8858 PRINTeD IN CHINA
MODEL H8120
6" RANDOM ORBITAL SANDER
INSTRUCTION SHEET
A
e
D
Figure 1 Model H8120 inventory.
.
Assembly
1. Install the ⁄ " NPT male quick-connect fitting
1
4
into the air inlet.
2. Attach a 6" hook and loop sanding disc to the
sanding pad as shown in Figure 2.
Figure 2. Attaching sanding disc.
B
F
C
