SHINDAIWA GRASS TRIMMER TO BRUSHCUTTER
CONVERSION KIT FOR T254 GRASS TRIMMER
MODEL: BCK-11
WARNING!
Minimize the risk of injury to yourself and others! Read the Owner's/Opera-
tor's manual originally supplied with the unit that is being upgraded and
familiarize yourself with the contents. Always wear eye and hearing protec-
tion when operating your unit.
Advertisement
Table of Contents
Related Manuals for Shindaiwa BCK-11
Summary of Contents for Shindaiwa BCK-11
- Page 1 SHINDAIWA GRASS TRIMMER TO BRUSHCUTTER CONVERSION KIT FOR T254 GRASS TRIMMER MODEL: BCK-11 WARNING! Minimize the risk of injury to yourself and others! Read the Owner's/Opera- tor's manual originally supplied with the unit that is being upgraded and familiarize yourself with the contents. Always wear eye and hearing protec- tion when operating your unit.
-
Page 2: Table Of Contents
The instructions described in this manual are intended to help Always wear a harness when operating this unit you get the most from your Shindaiwa power tool as well as with a blade. A harness to protect you and others from harm. These procedures are is also recommended when using trimmer line. -
Page 3: General Safety Instructions
Safety Labels IMPORTANT! Safety and Operation Information Labels: Make sure all information labels are undamaged and readable. Immediately replace damaged or missing information labels. A new label is provided in this kit and additional labels are available from your local authorized Shin- daiwa dealer. -
Page 4: Assembly
Assembly Install Metal Shield Parts Required: Metal Shield, Shield Bracket, 3 - 5 x 10 mm screws w/captivated flat and lock- washer, (metal shield to gear housing). 2 - 5 x 8 mm screws, 2 - 5 mm nuts, 2 - 5 mm lock- washers, (bracket to shield). - Page 5 Remove Handle Assembly 1. Remove handle assembly. Retain all parts for future use. Disconnect Throttle Cable-Ignition Wires 1. Loosen air cleaner cover knobs and remove air cleaner cover. 2. Remove wire end of throttle linkage cable (I) from carburetor throttle swivel hole.
-
Page 6: Throttle Linkage And Ignition Leads
Install Harness Hanger 1. Remove handle shim (P). 2. Slide harness hanger (Q) on to outer drive shaft tube (R) and loosely at- tach with 5 mm x 12 mm screw. Install Power Head 1. Slide outer drive shaft assembly into power head clamp, and align power head with gear case. -
Page 7: Install Blade
Install Blade Parts Required: Adapter plate w/25 mm diameter pilot, lower blade mounting plate, 10 mm hex nut w/L.H. thread, 2 mm x 25 mm cotter pin, blade w/25 mm arbor diameter. Install adapter plate (X) on splined PTO shaft, pilot side down. Blade installa- tion requires Adapter Plate (X) with 25 mm pilot. -
Page 8: Shoulder Strap
Shoulder Strap Adjust the shoulder strap so the shoulder pad rests comfortably on the off-side shoulder and the cutting path of the cutting attachment is parallel to the ground. Tighten hanger screw. WARNING! Always wear a shoulder strap when operating this unit with a blade. A shoulder strap is also recommended when using trimmer line. -
Page 9: Using A Brushcutter Blade
Using A Brushcutter Blade WARNING! Before working with a blade-equipped unit, always inspect and clean the area of objects that could interfere with or damage the blade. Never use a blade near sidewalks, fence posts, buildings or other objects that could cause injury or damage. ... - Page 10 NOTES...
- Page 11 NOTES...
- Page 12 If you require assistance or have questions concerning the application, operation or maintenance of this product you may call the Shindaiwa Consumer Product Support Department at 1-877-986-7783 from 8:30 am to 4:30 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial number of your unit.
