English...................1
Francais...............25
Italiano.................49
SHINDAIWA OWNER'S/OPERTOR'S MANUAL
T350 GRASS TRIMMER
C350/B450 BRUSHCUTTER
Read this manual and familiarize yourself with its contents.
This machine is designed for cutting grass, weed, and bushes.
Do not use this machine for other purposes.
Minimize the risk of injury to yourself and others.
Do not operate or service this machine unless you clearly understand
this manual.
Keep this manual at a particular place so that you can reread it when-
ever you have a question about its use.
Part Number 62102-94310 Rev. 02/05
C350/B450
WARNING!
T350
Advertisement
Table of Contents
Related Manuals for Shindaiwa B450
Summary of Contents for Shindaiwa B450
- Page 1 English...1 Francais...25 Italiano...49 SHINDAIWA OWNER’S/OPERTOR'S MANUAL T350 GRASS TRIMMER C350/B450 BRUSHCUTTER WARNING! Read this manual and familiarize yourself with its contents. This machine is designed for cutting grass, weed, and bushes. Do not use this machine for other purposes. Minimize the risk of injury to yourself and others.
-
Page 2: Table Of Contents
Introduction Shindaiwa 350 and 450-series hand held power equipment has been designed and built to deliver superior performance and reliability without compromise to quality, comfort, safety or durability. Shindaiwa’s high-performance engines represent the leading edge of -cycle engine technology, delivering exceptionally high power with remarkably low displace- ment and weight. -
Page 3: General Safety Instructions
General Safety Instructions Work Safely Trimmers and brushcutters operate at very high speeds and can do serious damage or injury if they are misused or abused. Never allow a person without training or instruc- tion to operate this unit! WARNING! Never make unauthorized attachment installations. -
Page 4: The Properly Equipped Operator
Wear hearing protection devices and a broad-brimmed hat or helmet. Wear close-fitting clothing to protect legs and arms. Gloves offer added protection and are strongly recom- mended. Do not wear clothing or jewelry that could get caught in machinery or underbrush. -
Page 5: Safety Labels
IMPORTANT! Safety and Operation Information Labels: Make sure all informa- tion labels are undamaged and readable. Immediately replace damaged or missing information labels. New labels are available from your local authorized Shin- daiwa dealer. T350 C350/B450... -
Page 6: Unit Description
98 dB (A) 110 dB (A) 2.3/1.3 m/s WOT (Left/Right) 5.3/6.8 m/s T350 TRIMMER Grip Ignition Switch Tank Throttle Guard Trigger Shoulder Harness C350/B450 BRUSHCUTTER Ignition Switch Trigger Tank Guard Handlebar Shoulder Harness C350/EC1 B450/EC1 S350EC1 S450EC1 33.6 cm 41.5 cm... -
Page 7: Assembly Procedure
Carefully inspect all components for damage. IMPORTANT! The terms “left”, “left-hand”, and “LH”; “right”, “right-hand”, and “RH”; “front” and “rear” refer to directions as viewed by the operator during normal operation. T350 ENGINE ASSEMBLY C350/B450 ENGINE ASSEMBLY SHOULDER STRAP HARNESS... - Page 8 (10) Put the bolt through the hole of the ground wire terminal and tighten the bolt. Assembly of the Outer Tube C350/B450 (1) Loosen the joint bolts fully and slip the outer tube into the joint until the tube bottoms (up to the insert label).
-
Page 9: Throttle Cable Adjustment
HANDLE OUTER TUBE BARRIER BOLT BARRIER Assembly of the Handle C350/B450 (1) Loosen the two bolts of the lower cap and remove the lower cap. (2) Position the handle bracket against the handle label located on the outer tube. (3) Attach the lower cap with the two bolts and tighten the bolts. -
Page 10: Cutting Attachment Shield Assembly
Cutting Attachment Shield Assembly WARNING! NEVER operate this machine without the cutting attachment shield. Operating without the cutting attachment shield may result in seri- ous injury. (A) Cutting Attachment Shield (1) Insert the cutting attachment shield between the outer tube and the lower clamp. -
Page 11: Installing A Blade
Installing a Blade (1) Make sure the switch is off and the engine is stopped. (2) Wear gloves to protect your hands. (3) Turn the unit over so the saw holder flange extending from the gear case is facing up. (4) Using the small end of the plug wrench, loosen the bolt (turn clock- wise) and remove the bolt, bolt guard,... -
Page 12: Mixing Fuel
WARNING! Minimize the risk of fire, burns, and personal injury! STOP engine before refueling. ALWAYS allow the engine to cool before refueling ALWAYS open the fuel cap slowly to allow any pressure build-up in the tank to release fuel vapor slowly. -
Page 13: Starting The Engine
WARNING! Never operate the engine without the cutting attach- ment installed. Starting a Cold Engine and/or Restarting After Refueling. T350 C350/B450 THROTTLE LEVER ON-OFF SWITCH THROTTLE LOCK BUTTON LOCK LEVER (a) Slide the ON-OFF switch to the “I”... -
Page 14: Stopping The Engine
(3) Adjust the length of the strap so that you can hold and operate the machine comfortably. (4) Make sure the hip pad stays be- tween your hip and outer pipe. (B450 ONLY) C350 B450 T350... -
Page 15: Operation
THICKNESS: 2.0mm Trimmer Heads (A) C350 PART NUMBER 78820-16000 TAP & FEED TRIMMER HEAD BOLT DIAMETER: 10mm THREAD: LEFT,1.25mm PITCH (B) B450 PART NUMBER 78820-14000 SEMI-AUTOMATIC TRIMMER HEAD BOLT DIAMETER: 10mm THREAD: LEFT,1.25mm PITCH (C) T350 PART NUMBER 78820-15000 TAP & FEED TRIMMER HEAD BOLT DIAMETER: 8mm THREAD: LEFT,1.25mm PITCH... -
Page 16: Using A Brushcutter With A Trimmer Head
Using a Brushcutter With a Trimmer Head You may install one of several types of Shin- daiwa trimmer heads on your TC350/B450 trimmer or brushcutter, each with features for specific applications and/or operational requirements. For proper operation, always refer to the instructions accompanying the trimmer head being used. -
Page 17: Hour Maintenance
10 Hour Maintenance Remove the air cleaner element from the carburetor and clean it thorough- ly with soap and water. Squeeze out excess, let dry and reassemble the element. CAUTION! Do not operate the machine if the air cleaner or element is damaged, or if the element is water-soaked. -
Page 18: Long Term Storage
Long Term Storage Whenever the unit will not be used for 30 days or longer, use the following procedures to prepare it for storage: Clean external parts thoroughly and apply a light coating of oil to all metal surfaces. ... -
Page 19: Troubleshooting Guide
Troubleshooting Guide What To Check Does the engine crank? Good compression? Does the tank contain fresh fuel of the proper grade? Is fuel visible and moving in the return line when priming? Is there spark at the spark plug wire terminal? Check the spark plug. - Page 20 Troubleshooting Guide (Continued) What To Check Is the engine overheating? Engine is rough at all speeds. May also have black smoke and/or unburned fuel at the exhaust. Engine is knocking. Low Power Output Possible Cause Remedy Operator is overworking Cut at a slower rate. the unit.
- Page 21 Troubleshooting Guide (Continued) Symptom Poor acceleration. Engine stops abruptly. Engine difficult to shut off. Cutting attachment moves at engine idle. Excessive vibration Attachment will not rotate Additional Problems Possible Cause Remedy Clogged air filter. Clean or replace the air filter. Clogged fuel filter.
-
Page 22: Declaration Of Conformity
We hereby declare the Shindaiwa Engine Engine Brushcutter, Model RM 350 (T350/EC1, C350/EC1). meets the following respective requirements. Council Directives: 89/336/EEC as amended 98/37/EC as amended 2000/14/EC as amended 2004/26/EC as amended Measured sound power level: 113dB(A) Guaranteed sound power level: T350/EC1:114dB(A), C350/EC1:115dB(A) Technical documentation is kept by: K. - Page 23 We hereby declare the Shindaiwa Engine Engine Brushcutter, Model RM 450 (T450/EC1, B450/EC1). meets the following respective requirements. Council Directives: 89/336/EEC as amended 98/37/EC as amended 2000/14/EC as amended 2004/26/EC as amended Measured sound power level: 115dB(A) Guaranteed sound power level: 117dB(A) Technical documentation is kept by: K.
- Page 24 Shindaiwa Inc. 11975 S.W. Herman Rd. Tualatin, Oregon 9706 USA Telephone: 503 69-3070 Fax: 503 69-6696 www.shindaiwa.com Shindaiwa Kogyo Co., Ltd. Head Office: 6--11, Ozuka-Nishi Asaminami-Ku, Hiroshima 731-3167, Japan Telephone: 81-8-849-0 Fax: 81-8-849-481 ©005 Shindaiwa, Inc. Part Number 610-94310 Revision /05 Shindaiwa is a registered trademark of Shindaiwa, Inc.
