- Page 1 WS-7047U Wireless 433 MHz Weather Station With Rainfall and Temperature Instruction Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Topic Page Inventory of Contents Additional Equipment Quick Setup Detailed Setup Guide Battery Installation Mounting Operation of the Wireless Weather Station Troubleshooting Maintenance and Care Specifications Warranty Information 10-11 INVENTORY OF CONTENTS 1. The digital indoor weather station. 2. -
Page 3: Quick Setup
QUICK SETUP OF THE WIRELESS WEATHER STATION Hint: Use good quality Alkaline Batteries and avoid rechargeable batteries. For best performance and longest life we recommend using RadioShack alkaline batteries. 1. Have the indoor weather station, remote temperature sensor and remote rain sensor 3 to 5 feet apart. -
Page 4: Detailed Setup Guide
DETAILED SET-UP GUIDE FOR THE WIRELESS WEATHER STATION I) Battery Installation Note: Batteries will fit tightly. To avoid start-up problems make sure that the batteries do not spring free. A) Remote Rainfall Sensor Battery compartment Battery cover 1. Remove the flat-head screw and battery cover located on the underside of the base. - Page 5 Note: To achieve a true temperature reading, avoid mounting in direct sunlight. We recommend that you mount the remote temperature sensor on a North-facing wall. The sending range is 80ft; obstacles such as walls, concrete, and large metal objects will reduce the range. Place both units in their desired location before permanently mounting.
-
Page 6: Mounting
The remote temperature sensor can be mounted in two ways: • with the use of screws • using the adhesive tape A. Mounting with Screws 1. Remove the mounting bracket from the remote temperature sensor. 2. Place the mounting bracket over the desired location. Through the three screw holes of the bracket, mark the mounting surface with a pencil. -
Page 7: Operation Of The Wireless Weather
OPERATION OF THE WIRELESS WEATHER STATION A) Viewing the Temperature (Remote and Indoor) The indoor temperature will display in the Temperature portion of the LCD. To View the remote temperature press and release the “RESET” button. Press and release the “RESET” button to return to the indoor temperature. B) Viewing the Rainfall The rainfall total will be displayed in the Rainfall portion of the LCD. -
Page 8: Maintenance And Care
Solution: Replace batteries Problem: No outdoor temperature is displayed. Solution: 1. Remove all batteries, reinsert into remote rain sensor first, then into the remote temperature sensor and then into the indoor temperature station. 2. Place remote temperature sensor closer to the indoor weather station. 3. -
Page 9: Specifications
Warranty service can only be performed by a La Crosse Technology, Ltd authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center. - Page 10 La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of La Crosse Technology, Ltd and must be returned to La Crosse Technology, Ltd.
- Page 11 For warranty work, technical support, or information contact: La Crosse Technology 2809 Losey Blvd. S. La Crosse, WI 54601 Phone: 608.782.1610 Fax: 608.796.1020 e-mail: support@lacrossetechnology.com (warranty work) sales@lacrossetechnology.com (information on other products) web: www.lacrossetechnology.com FCC ID: OMO-01RX (Receiver), OMO-01TX (sensor) THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
