RCR-2
GB
Version 1

Advertisement

Table of Contents
loading

Related Manuals for Sangean RCR-2

Summary of Contents for Sangean RCR-2

  • Page 1 RCR-2 Version 1...

  • Page 2: Important Safety Instructions

    Important safety instructions 1. Read and understand all safety and operating instructions before the radio is operated. 2. Retain instruction: The safety and operating instructions should be retained for future reference. 3. Heed warnings. All warnings on the appliance and operating instructions should be followed.
  • Page 3 10. Power cords: The power cord should be positioned so it is not walked on, pinched, or items placed on top of it. Pay particular attention to cords at plugs, convenience receptacles, and the point where they exit from the unit. Unplug the power cord by gripping the power plug, not the cord.

  • Page 4: Main Features

    Main features ( 1 ) 14 station memories ( 7 each on MW/FM bands ) ( 2 ) Digital radio controlled clock with date display Date and time displays are checked and if necessary corrected daily with an exact radio controlled time antenna signal ( 3 ) Nap timer Adjustable from 10-120 minutes ( 4 ) Alarm with Humane Wake System ( HWS )
  • Page 7 Controls Power on/off and Sleep timer Nap timer Display button to display time and radio frequency Display backlight on/off button Buzzer alarm level adjustment RESET Time zone adjustment Date adjustment Time adjustment Alarm 2 button Alarm 1 button Headphones socket Time/Date/Alarm set button LCD display Tuning Up/Down and Snooze button...

  • Page 8: Lcd Display

    LCD display Radio band and a.m./p.m. display Time set Daylight Saving Time (D.S.T.) Alarm indicator Sleep timer Nap timer Alarm a.m./p.m. indicator Date Week day Month/Date/Year/alarm time Radio controlled symbol Station memory number and second indicator Minute ( for Nap and Sleep timer ) Frequency/Time display...

  • Page 9: Notes On Safety

    Notes on safety Only operate this appliance with a power supply of 220-230 Volt/ 50-60 Hz . If you intend not using the appliance for a longer period of time ( eg. Holidays), pull the plug out of the mains socket to ensure a complete separation from the power supply.

  • Page 10: Manual Time Setting

    If the symbol blinks irregularly, try to improve the reception of the radio controlled time signal by re-allocating the radio, or rotate or extend the external antenna. If the time signal can not be received in your area, you will have to set the time and date manually. Note : To activate radio controlled time check manually, press Time button 9 for more than 4 seconds, the appliance will start to search radio...

  • Page 11: Radio Operation

    DATE Press DATE button, display DATE will blink. Press SET button, display will blink year with a beep and a small Y (year) will appear, 1. Set the year with key + or -. 2. Press SET button again and follow the setting of year to set the month and date .

  • Page 12: Alarm Clock

    Storing the preset stations Tune into the stations. Select a memory preset button and press for more than 2 seconds until a confirmed beep sounds and display M stops blinking. The station is now stored. Note: When you store a new station in a memory slot, the station previously in that slot is automatically erased.
  • Page 13 Alarm with radio If you like to be awoken by the radio station you are listening, press Alarm system 1 or 2 for more than 2 seconds, the appliance will store the radio alarm station, then follow procedures 1-7 to set radio alarm.
  • Page 14 Alarm with HWS alarm buzzer 1. Select alarm system 1 or 2 by pressing the alarm 1 or 2 button (11 or 10). Display will blink selected alarm system symbol. 2. Press alarm SET button 13, display will blink both alarm hour and alarm mode with a beep.

  • Page 15: Nap Timer

    4. Press alarm 1 or 2 button again to confirm alarm cancellation. symbol will stay on the display for around 2 seconds and disappear. Note: You may also select days of the week which you wish to be or not to be woken after pressing SET button while display is blinking days of the week.

  • Page 16: Display Backlight On/Off

    SLEEP – auto shut off Continuously pressing the Power button 1 will activate the sleep function, the radio will switch off automatically in 15 minutes step from 15-120. The Sleep control begins when you release the key and display will appear. After the minutes which selected, the radio turns itself off automatically.

  • Page 17: Time Zone Switch

    Time Zone switch In normal case, please set time zone switch to 0 position. For some countries where don’ t provide radio controlled time facility but still can receive radio controlled time signal from nearby countries . If the time zone is different, you may use the time zone switch to correct the time.

  • Page 18: Technical Data

    Technical data Power supply 220-230 Volt/50-60 Hz Output Power 800 mW max Power consumption 7W (max.). Frequency coverage FM 87.50 - 108 .0 MHz MW 522 - 1629 kHz Technical data subject to changes without prior notice.
