Sangean RCR-2 Operating Instructions Manual

Sangean rcr-2 clock radio operating instruction
Hide thumbs Also See for RCR-2:

Advertisement

Table of Contents

See also: User Manual
TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW-
HEAD WITHIN THE
TRIANGLE IS A WARN-
ING SIGN ALERTING
YOU OF "DANGEROUS
VOLTAGE" INSIDE THE
RADIO.
WARNING:
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE
RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
THE BACK, NO USER SER-
VICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE PER-
SONNEL.
RCR-2
Operating instruction
!
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A WARN-
ING SIGN ALERTING
YOU OF IMPORTANT
INSTRUCTIONS
ACCOMPANYING THIS
RADIO.
GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RCR-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sangean RCR-2

Summary of Contents for Sangean RCR-2

  • Page 1 VICEABLE PARTS INSIDE. ING SIGN ALERTING REFER SERVICING TO YOU OF “DANGEROUS QUALIFIED SERVICE PER- VOLTAGE” INSIDE THE SONNEL. RADIO. RCR-2 Operating instruction THE EXCLAMATION POINT WITHIN THE TRIANGLE IS A WARN- ING SIGN ALERTING YOU OF IMPORTANT INSTRUCTIONS ACCOMPANYING THIS...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’...
  • Page 3 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.

  • Page 4: Main Features

    Main features ( 1 ) 14 station memories ( 7 each on AM/FM bands ) ( 2 ) Digital radio controlled clock with date display Date and time displays are checked and if necessary corrected daily with an exact radio controlled time antenna signal ( 3 ) Nap timer Adjustable from 10-120 minutes ( 4 ) Alarm with Humane Wake System ( HWS )
  • Page 7 Controls Power on/off and Sleep timer Nap timer Display button to display time and radio frequency Display backlight on/off button Buzzer alarm level adjustment RESET Time zone adjustment Date adjustment Time adjustment Alarm 2 button Alarm 1 button Headphones socket Time/Date/Alarm set button LCD display Tuning Up/Down and Snooze button...

  • Page 8: Lcd Display

    LCD display Radio band and a.m./p.m. display Time set Daylight Saving Time (D.S.T.) Alarm indicator Sleep timer Nap timer Alarm a.m./p.m. indicator Date Week day Month/Date/Year/alarm time Radio controlled symbol Station memory number and second indicator Minute ( for Nap and Sleep timer ) Frequency/Time display...

  • Page 9: Notes On Safety

    Notes on safety Only operate this appliance with a power supply of 110-120 Volt/ 50-60 Hz . If you intend not using the appliance for a longer period of time ( eg. Holidays), pull the plug out of the mains socket to ensure a complete separation from the power supply.

  • Page 10: Manual Time Setting

    Set time Zone Switch [7] located on bottom of clock to your correct zone as illustrated. After the ATS program completes the AM/FM frequency set up the following display — : — will appear and the symbol will blink indicating the radio is searching for the radio controlled signal. Once the radio receives the radio controlled signal the correct time and date will be set automatically.
  • Page 11 Note: If there is Daylight Saving Time ( D.S.T.) system in your place, after pressing SET button, press Mode button once will advance one hour on time setting, Display will show D.S.T. symbol indicating the time is under D.S.T. status. DATE Press DATE button, display DATE will blink.

  • Page 12: Radio Operation

    Radio operation Turn on the radio with the Power on/off key 1. Tune into desired stations Manual station selection 1. With the key 15 Tuning + and -, you can tune into the frequency of your desired stations. 2. Scanning tuning Press and hold key 15 + or –...

  • Page 13: Alarm Clock

    Alarm Clock Alarm setting can be done while the appliance power is during on or off position. The alarm clock is equipped with two alarm systems which can be operated independently of each other either with Human Wake System buzzer or with a radio (radio alarm clock ). Alarm with radio 1.
  • Page 14 Note: If you like to be awoken by the radio station you are listening, press Alarm system 1 or 2 for more than 2 seconds, the appliance will store the radio alarm station, then follow above procedures 2-8 to set radio alarm. Alarm with HWS alarm buzzer 1.
  • Page 15 Cancel alarm setting. If you do not wish to be woken up at the alarm time you have set, you can cancel the alarm function. 1. Select alarm system 1 or 2 by pressing the alarm 1 or 2 button (key 11 or 10).

  • Page 16: Nap Timer

    Nap timer With key 2, you can select the period for the short term alarm in 10 minutes steps from 10-120 minutes. The Nap timer starts when you release the key. NAP will appear on display. The alarm signal sounds after the period of time which you have set.

  • Page 17: Display Backlight On/Off

    Alarm level adjustment With alarm level adjustment switch 5, you may select required alarm signal level. Note: Alarm level adjustment works only for buzzer alarm. Display backlight on/off Key 4 provides you to select whether you require to illuminate the display. Time zone switch Time Zone Switch [7] should be set to zone where clock/radio is to be used.

  • Page 18: Technical Data

    Technical data Power supply 110-120 Volt/50-60 Hz Output Power 800 mW max Power consumption 7W (max.). Frequency coverage FM 87.50 - 108 .0 MHz AM 520 - 1710 kHz Technical data subject to changes without prior notice.
  • Page 19 381J412A...
