Sangean RCR-24 Instructions Manual

Hide thumbs Also See for RCR-24:
Table of Contents

Advertisement

Quick Links

Download this manual
RCR-24
中文
GB
Version 1

Advertisement

Table of Contents
loading

Related Manuals for Sangean RCR-24

Summary of Contents for Sangean RCR-24

  • Page 1 RCR-24 中文 Version 1...
  • Page 2 AC Adapter are stated on the final page of the manual, or please contact Sangean for the correct AC Adapter and specifications. For customers in the US and Canada, please call 888-726-4326 or 562-94-9900. For all other areas, please contact us via info@ sangean.com.tw.

  • Page 3: Important Safety Instructions

    Your radio is equipped with the DOE (Department of Energy) new energy saving AC Adapter. Sangean suggest that you keep your AC Adapter at least 2 inches away from the radio while listening to the AM Band in order to eliminate any interference caused by the AC Adapter.
  • Page 4 For North America users: FCC Cautions to the user The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF exposure statements IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 5 (Sold only in North America)

  • Page 6: Lcd Display

    Control Preset button Tuning up/down button Standby button/Sleep button Time setting button Alarm 2 button Alarm  button Display button/Stereo/Mono button Source button/Step button Snooze/Dimmer button Volume up/down button LCD display Speaker FM antenna Headphone socket Auxiliary input socket DC IN socket Backup battery compartment (Only available to customers purchased in North America) LCD display Stereo indicator...

  • Page 7: Using The Radio For The First Time

    Using the radio for the first time Using the AC power adaptor The AC power adaptor required for this unit should be 7.5 volts DC at 0.8A center pin positive. Insert the adaptor plug into the DC socket on the rear of the radio. Plug the adaptor into a standard electrical outlet.

  • Page 8: Presetting Am/Fm Stations

    Scan tuning AM/FM . Fully extend the FM wire antenna located on the rear of your clock radio. Place the wire antenna so that it is as straight as possible extending either above or below the radio. 2. Press the Standby button to turn on your radio. 3.

  • Page 9: When The Alarm Sounds

    3. Press the Tuning up/down to choose the required alarm type, andthen press the Alarm button to confirm the setting. The alarm can be set to buzzer ( ), or radio ( FM, AM mode. When the buzzer mode is selected, please go to step 4 directly to set alarm volume. When radio mode is selected, the frequency band on the display will begin to flash.

  • Page 10: Dimmer Control

    Sleep timer - radio auto shut off Your radio can be set to turn off automatically after a preset time has elapsed. The Sleep Timer setting can be adjusted between 5, 30, 45, 60, 90 and 20 minutes. . Press and hold the Standby button to enter the Sleep Timer setting. Sleep timer icon will show on the display.

  • Page 11: Auxiliary Input Socket

    Setting tuning step 4. After the FM range setting is completed, FM tuning step setting will flash on the display (e.g. FM 100). Press the Tuning up/down button to select the desired FM tuning step (50 kHz or 100 kHz) and press the Source button to confirm the setting.

  • Page 12: Specifications

    Auxiliary socket: 3.5mm dia stereo Antenna System FM Wire Antenna/AM Built-in Ferrite Bar Sangean reserves the right to amend the specification without notice. If at any time in the future you should need to dispose of this product please note that: Waste electrical products should not be disposed of with household waste.
