Multi-Device Settings - Kogan KAIPC01BLKA User Manual

UPnP set: If you want internet access to IPCAM, ensure that the state is correct
UPnP.
Device Firmware Upgrade: The system firmware update.
Restore factory settings : When there is not a response when the error
occurred, you can restore the factory settings to reset the device.
Reboot the device: Restart the device.
Back: Return to monitor mode

3.4.1 Multi-Device Settings

Add a local area network equipment
In the multi-device configuration page, you can see all the equipment attached to
the LAN. The first device is the default device. You can add more devices listed in
the list of equipment. Embedded applications, up to 4 devices at the same time.
Click "second road equipment" and double-click "Current list of devices in the
LAN" in the device entry name, host address, Http port will automatically be filled.
Requires the user to fill in the correct account name and password, click "Add."
Repeat this process to continue to add devices. Finally do not forget to click on
the "Settings" button.
Add a device on the internet
First, make sure you want to add devices to access via IP address or domain
name. For example: http://202.96.133.134: 9008 or http://IPcam.dyndns.org:9008.
Then fill in the host address: 202.96.133.134 HttpPort: 9008 or host address:
IPcam.dyndns.org Http port: 9008. Fill in the above correct account name and
password and click "Add." Repeat the above steps to add other devices.
Figure3.9
14
