Professional Two-Way Radio
PT Series User Manual
Models: VHF PT-150 • UHF PT-450
•
•
•
•
•
•
505 W. Carmel Drive/P.O. Box 1998, Carmel, IN 46032 • P.O. Box 1998 • Phone: 317.846.1201 • Email: sales_info@ritron.com
© 2010 Ritron, Inc. All rights reserved. Ritron is a registered trademark of Ritron, Inc. All other trademarks are the property of their
respective owners. Ritron PN: V 5/2013
Analog, Narrow Band Capable
Narrower Frequency Channel Steps
VHF: 2.5 / 12.5kHz
UHF: 2.5 / 6.25/ 12.5kHz
2-Tone Decode 300-3000Hz
Loud Audio Output - 1000mW
MIL STD 810F Temperature/Humidity/
Shock/Vibration
IP65 Certified Resistance to Water/Dust
800-USA-1-USA (872-1-872)
www.ritron.com
Default Frequencies and Settings
Dear Customer,
Thank you for your purchase of the PT Series radio. Each PT-150 and
PT-450 radio comes pre-programmed with the *4 factory default chan-
nel frequencies listed below. The frequencies cannot be changed via the
keypad buttons. Other factory default radio settings i.e. Programmable
Function Buttons are listed on Page 6 to 10.
If your company currently has an FCC license on frequencies other than
the default settings, the PT radio can be PC programmed to custom
frequencies using optional Ritron PC software, other settings can also
be re-configured. Please contact Ritron, Inc. toll free at 800-872-1872
for information on "custom" radio programming services.
Please be advised that operation on the factory default frequencies
require that you obtain an FCC Operator License BEFORE USE.
VHF PT-150 Default Frequency Settings - Operating band *136-174MHz
Ch1 FC # 3 (151.6250MHz) Narrow Band - no tone - 2/5 Watts
Ch2 FC # 4 (151.9550MHz) Narrow Band - no tone - 2/5 Watts
Ch3 FC #15 (154.4900MHz) Narrow Band - no tone - 2/5 Watts
Ch4 FC # 7 (154.5150MHz) Narrow Band - no tone - 2/5 Watts
UHF PT-450 Default Frequency Settings - Operating band *406-470MHz
Ch1 FC # 5 (467.8500MHz) Narrow Band - no tone - 2 Watts
Ch2 FC # 8 (467.9250MHz) Narrow Band - no tone - 2 Watts
Ch3 FC # 3 (464.5500MHz) Narrow Band - no tone - 2/4 Watts
Ch4 FC # 6 (467.8750MHz) Narrow Band - no tone - 2 Watts
FC# = Frequency Code, Narrow Band = 12.5KHz bandwidth
Tone = tone codes can be added via the keypad by the radio user.
See page 10 for details.
The standard antenna supplied is cut for operation in the
following frequency bands:
VHF: 150-165MHz
UHF: 450-470MHz
Operation on frequencies outside this range will require a
custom cut antenna.
