HOMELITE BACKPACKER II BLOWERS – MODEL NUMBERS UT08072, UT08572 AND UT08572A
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
BLOWER or when ordering repair parts.
KEY
PART
NO.
NUMBER
DESCRIPTION
1
65008001
VIBRATION ISOLATOR ........................................

900968001
FOAM PAD ..........................................................1

678108001
SQUARE NUT .....................................................
4
51809001
PUSH CLIP ..........................................................6
5
660678001
* SCREW (1/4-0 x /4 in.) ....................................
6
678110001
FLAT WASHER ....................................................4
7
51809001
BLOWER FRAME ................................................1
8
68085001
FRAME BRACKET ...............................................1
9
68155001
ISOLATOR BRACKET ..........................................1
10
678109001
LOCK WASHER...................................................4
11
678111001
* HEX NUT .............................................................6
1
67811001
WING NUT ...........................................................1
1
66069001
* SCREW (10-14 x /4 in. TORX TRUSS HD.) .......
14
580577001
SWEEPER NOZZLE .............................................1
15
580569001
STRAIGHT TUBE .................................................
16
760600
SWITCH ...............................................................1
17
580567001
HANDLE CONTROL - RT ....................................1
18
580568001
HANDLE CONTROL - LT .....................................1
19
660680001
BOLT ...................................................................1
PARTS LIST
QTY
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
(FIGURE
A)
KEY
PART
NO.
NUMBER
DESCRIPTION
0
518090001
TRIGGER LATCH .................................................1
1
518091001
TRIGGER .............................................................1

940615001
BACKPACKER LABEL .........................................1

580565001
ELBOW ................................................................1
4
900971001
CARRYING STRAP ..............................................
5
4800600
CLAMP ................................................................1
6
580566001
BELLOWS ...........................................................1
7
4800600
TUBE CLAMP ......................................................
8
580570001
UPPER TUBE ......................................................1
9
65001001
CABLE BRACKET (NOT SHOWN) ......................1
0
7000001
HARNESS WIRES & THROTTLE
(NOT SHOWN) .....................................................1
1
68081001
TAB (MALE 50 x 0, NOT SHOWN) ................1

900969001
SAFETY STRAP (NOT SHOWN) ..........................1

90097001
NYLON TIE STRAP (NOT SHOWN) .....................1
98000595
OPERATOR'S MANUAL (96077008)
9800078
OPERATOR'S MANUAL (UT0857A)
8-07-08
(REV:05)

QTY
