OPERATOR'S MANUAL
VAC ATTACK II
UT08544/UT08546
Your blower has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAC ATTACK II UT08544 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Homelite VAC ATTACK II UT08544

Summary of Contents for Homelite VAC ATTACK II UT08544

  • Page 1 OPERATOR’S MANUAL VAC ATTACK II UT08544/UT08546 Your blower has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS  Introduction ... 2  General Safety Rules ... 3  Specific Safety Rules ... 4  Symbols ... 5-6  Features ... 7-8  Assembly ... 9-11  Operation ... 12-15  Maintenance ... 16-17  Troubleshooting ... 18 ...

  • Page 3: General Safety Rules

    WARNING: READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS  Do not allow children or untrained individuals to use this unit.  Never start or run the engine inside a closed area; breath- ing exhaust fumes can kill.

  • Page 4: Specific Safety Rules

     Do not operate vacuum without vacuum bag installed; flying debris could cause serious injury. Always close vacuum bag completely before operating.  Always hold the blower in your right hand, refer to the OPERATION section, later in this manual for additional information.

  • Page 5: Symbols

    SYMBOL NAME Safety Alert Symbol Read the Operator’s Manual Wear Eye and Hearing Protection Long Hair Blower Tubes Vacuum Door Loose Clothing Gasoline and Oil SYMBOLS EXPLANATION Precautions that involve your safety.

  • Page 6: Symbols

    To avoid serious personal injury, do not attempt to use this product until you read thoroughly and understand com- pletely the operator’s manual. If you do not understand the warnings and instructions in the operator’s manual, do not use this product. Call Homelite customer service for assistance. Page 6...

  • Page 7: Product Specifications

    Engine displacement ...30cc Air Velocity: MPH ...200 CFM ...420 HIGH VELOCITY NOZZLE WET LEAF WIDE SWEEPER SCRAPER NOZZLE FEATURES UPPER HANDLE TUBE CLAMP BLOWER TUBE VACUUM HANDLE Page 7 CRUISE CONTROL (THROTTLE LOCK) THROTTLE TRIGGER INLET COVER DOOR KNOB DOOR Fig. 1...

  • Page 8: Features

    The blower is equipped with a mulcher feature that efficiently reduces leaves at a 12:1 ratio. THROTTLE TRIGGER The blower can be operated at any speed between idle and full throttle. VACUUM The blower will convert to a powerful vacuum/mulcher using no tools.

  • Page 9: Packing List

     If any parts are damaged or missing, please call 1-800-242-4672 for assistance. PACKING LIST Blower Blower Tube Wide Sweeper Nozzle High Velocity Nozzle Upper and Lower Vacuum Tubes Vacuum Bag Bag Adaptor...

  • Page 10: Assembling The Blower Tubes

     Place tube clamp around the neck of the blower housing outlet. Do not tighten the knob yet.  Align the locking tab on blower tube with the slot in the blower housing outlet; push the tube into the housing.

  • Page 11: Assembly

    Place the notch in the support arm of the upper vacuum tube under the hinge of the inlet cover door.  Push the upper vacuum tube into the blower housing.  Align the upper vacuum tube knob with the hole in the housing and tighten securely.

  • Page 12: Filling Tank

    WARNING: Do not allow familiarity with this product to make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury. WARNING: Always wear safety goggles or safety glasses with side shields when operating this product. Failure to do so could result in objects being thrown into your eyes resulting in possible serious injury.

  • Page 13: Starting And Stopping

    Never run the unit without the blower tubes installed or the vacuum door securely closed. Failure to heed this warning could result in serious personal injury.  Hold the blower with the upper handle in your right hand as shown. WARNING: Keep away from all hot surfaces of the blower.
  • Page 14  Watch out for children, pets, open windows or freshly washed cars, and blow debris safely away.  Use the full blower nozzle extension so the air stream can work close to the ground.  After using blowers or other equipment, CLEAN UP! Dispose of debris in trash receptacles.

  • Page 15: Vacuum Operation

    Hold the upper handle in your right hand and the vacuum handle in your left hand.  Move the blower from side to side along outer edge of the debris. To avoid clogging, do not place the vacuum tube directly into the debris pile.

  • Page 16: General Maintenance

    WARNING: When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. WARNING: Always wear safety goggles or safety glasses with side shields during power tool operation or when blowing dust. If operation is dusty, also wear a dust mask. GENERAL MAINTENANCE Avoid using solvents when cleaning plastic parts.

  • Page 17: Maintenance

    If you notice low power from the blower, have a qualified service technician check the exhaust port and muffler for carbon deposits. Removing the carbon deposits should restore performance to the blower.

  • Page 18: Troubleshooting

    IF THESE SOLUTIONS DO NOT SOLVE THE PROBLEM CONTACT YOUR AUTHORIZED SERVICE DEALER. PROBLEM POSSIBLE CAUSE Engine will not start 1. No spark. 2. No fuel. 3. Engine is flooded. Engine does not reach full 1. Incorrect oil/fuel mixture. speed and emits excessive smoke 2.

  • Page 19: Limited Warranty Statement

    HOMELITE brand product. Proof of purchase will be required by the dealer to substantiate any warranty claim. All warranty work must be performed by a Homelite authorized service center.
  • Page 20 U.S. EPA standards for the first two years of engine use from the date of sale to the ultimate purchaser. Homelite Consumer Products, Inc., must warrant the emission control system on your non-road or small off-road engine for the period of time listed above provided there has been no abuse, neglect, or improper maintenance of your non-road or small off-road engine.

  • Page 21: Warranty

    5 Hours Every 25 Hours or Yearly CALL US FIRST For any questions about operating or maintaining your product, call the Homelite Your product has been fully tested prior to shipment to ensure your complete satisfaction. Page 21 Clean Every...
  • Page 22 1-800-242-4672. Replacement parts can also be obtained at one of our Authorized Service Centers. • HOW TO LOCATE AN AUTHORIZED SERVICE CENTER: Authorized Service Centers can be located online at www.homelite.com or by calling 1-800-242-4672. • HOW TO OBTAIN CUSTOMER OR TECHNICAL SUPPORT: To obtain Customer or Technical Support please contact us at 1-800-242-4672.
