1
0D7294
2
0A7822
3
026902
4
0C7907J
5
024526
6
057329
7
027482
8
022097
9
0C8275
(1)10
0D2572
11
090388
12
0A1495
(1)13
063617
14
047411
15
0A1661
16
0F4034
17
0F59350ST14
18
0F59390ST14
19
0G3259
20
0H7917
21
0F6165
22
0G5968C
0H8062C
0J3806C
23
064101
24
0F59400ST14
25
087680
26
063378
27
064761
28
063321
29
073590A
30
0D3587
31
067210A
32
0A9457
33
0D4545
34
0F6129
35
081221
36
0A8261
37
022473
(1)38
0H1605
39
PER ORDER
40
022129
41
091472
42
091472A
43
067989
44
0H7260
45
0H6389
46
0H7376A
47
0H7270
48
0H7274
49
091477
1
XFER SW-W 400A600V2P
6
LUG, SLDLS S 600/250-1/0X1/4-28
6
SCREW TAPTITE #8-32X1/4 BP
2
COVER LUG 2P 400AMP
1
SCREW HHTT 5/16-18 X 3/4 CZ
1
LUG, SOLDERLESS 350-#6X13/32 AL/CU
1
WASHER SHAKEPROOF EXT 5/16 STEEL
15
WASHER LOCK M6-1/4
4
SCREW PPHM DSEMS M4-.7 X 10 ZNC
1
FUSEBLO CK 30A 600V 3POS W/SQ
3
SCREW TAPTITE M6-1.0 X 12 MM
6
SCREW TAPTITE M4-.7 X 10 MM
1
RELAY PNL 12VDC DPDT 10A@240VA
2
SCREW HHC M6-1.0 X 16 G8.8
2
RIVET, P OP
1
ASSY. NEUTRAL BLOCK 300/400A
1
ENCLOSURE RTS 3R 24X36X10 GY4
1
COVER, NEMA 3R T/S ENCL GY 4
2
DECAL TERMINAL SHOCK HZD BI
1
DECAL TERMINAL STRIP
2
WASHER, NYLON
1
DECAL DATA XFER SW
1
DECAL DATA XFER SW
1
DECAL DATA XFER SW
6
NUT HEX FL WHIZ 3/8-16
1
SUBPLATE 24/36 ENCL RTS GY 4
1
NUT WING M6-1.0
4
HOLDER CABLE TIE
4
TIE WRAP UL 5.6" X .10" NATL
1
HANDLE TRANSFER SWITCH 1-400A
3
FUSE 5A X BS S HLDR73591
1
DECAL,FUSE REPLACEMENT
1
DECAL GROUND LUG
1
DECAL NEUTRAL
1
DECAL MANUAL OPERATIO N
1
DECAL, TES T SEQUENCE
1
DECAL, UL NAMEPLATE
12
SCREW, HHCS 1/4-28 X 5/8"
12
WASHER, FLAT 1/4-6M ZINC
1
BLO CK TERM 20A 5 X 6 X 1100V
1
DECAL, FRNT CVR ATS 3R NON
1
WASHER LOCK M8-5/16
2'
DUCT WIRING 1X1.5
2'
COVER WIRE DUCT 1 IN
2
NUT HEX FL WHIZ M8-1.25
1
HARNESS 400A 2 PO LE RTS (NOT SHOWN)
1
DECAL, UTILITY LOAD SENSE 240V
1
ASSY PCB AC LOAD CONTRO LLER
1
CHANNEL SNAPTRACK 76.2 X 101.2
1
DECAL 2008 NEC CO MPLIANCE
6
RIVET, WIRE DUCT MNT
(1) ITEMS INCLUDED WITH HARNESS
