Fujitsu Inverter Halcyon ASU9R2 Operating Manual
Heat & cool model (reverse cycle) room air conditioner all mounted type
Hide thumbs
Also See for Inverter Halcyon ASU9R2:
- Warranty statement (1 page) ,
- Service manual (20 pages) ,
- Installation manual (14 pages)
Table of Contents
Advertisement
Advertisement
Table of Contents
Related Manuals for Fujitsu Inverter Halcyon ASU9R2
Summary of Contents for Fujitsu Inverter Halcyon ASU9R2
- Page 3 Fig. 1 Indoor Unit Fig. 6 Remote Control Unit 1 Operating Control Panel (Fig. 2) H MASTER CONTROL button 2 MANUAL AUTO button I SET TEMP. / SET TIME buttons (+/-) J Signal Transmitter 3 Indicator Lamps (Fig. 3) K TIMER button 4 Remote Control Signal Receiver L FAN CONTROL button 5 OPERATION Indicator Lamp (red)
-
Page 4: Features And Functions
FEATURES AND FUNCTIONS AUTO CHANGEOVER WIRELESS REMOTE CONTROL UNIT The operation mode (cooling, heating) is switched The Wireless Remote Control Unit allows convenient con- automatically to maintain the set temperature, and the trol of air conditioner operation. temperature is kept constant at all times. SLEEP TIMER MILDEW-RESISTANT FILTER When SLEEP is selected be pressing TIMER button during... - Page 5 PREPARATION CAUTION! Turn on the Power G Take care to prevent infants from accidentally swallowing batteries. In the case of a direct line connection, turn on the circuit G When not using the remote control unit breaker. for an extended period, remove the batteries to avoid possible leakage and damage to the unit.
-
Page 6: Operation
OPERATION To Select Mode Operation Press the START / STOP button (Fig.6 M). The indoor unit’s OPERATION indicator lamp (red) (Fig. 3 5) will light. The air conditioner will start operating. Press the MASTER CONTROL button (Fig.6 H) to se- lect the desired mode. - Page 7 OPERATION About AUTO CHANGEOVER Operation G When AUTO CHANGEOVER operation first selected, the fan will oper- AUTO: ate at very low speed for about one minute, during which time the unit detects the room conditions and selects the proper operating mode. If the differance between thermostat setting and actual room tempera- ture is more than +4 °F →...
-
Page 8: Timer Operation
TIMER OPERATION Before using the timer function, be sure that the Remote Control Unit is set to the correct current time, see page 4. To Use the ON timer or OFF timer To Cancel the Timer Press the START / STOP button (Fig. 6 M). Use the TIMER button to select “TIMER RESET.”... -
Page 9: Sleep Timer Operation
SLEEP TIMER OPERATION Unlike other timer functions, the SLEEP timer is used to set the length of time until air conditioner operate is stopped. To Use the SLEEP Timer To Cancel the Timer: While the air conditioner is operating or stopped, press the Use the TIMER button to select “TIMER SLEEP button (Fig. -
Page 10: Adjusting The Direction Of Air Circulation
ADJUSTING THE DIRECTION OF AIR CIRCULATION Vertical (up-down) direction of airflow is adjusted by pressing the Remote Control Unit’s SET button. Horizontal (right-left) airflow direction is adjusted manually, by moving the Air Flow Direction Louvers. Whenever making horizontal airflow adjustments, start air conditioner operation and be sure that the vertical air direction louvers are stopped. -
Page 11: Swing Operation
SWING OPERATION Begin air conditioner operation before performing this procedure. To select SWING Operation Press the SWING button (Fig. 6 P). The SWING indicator lamp (orange) (Fig. 3 8) will light. In this mode, the Air Flow Direction Louvers will swing automatically to direct the air flow both up and down. -
Page 12: Cleaning And Care
CLEANING AND CARE G Before cleaning the air conditioner, be sure to turn off the power supply to the air conditioner. CAUTION! G Make sure the plasma filter unit is properly mounted before cleaning or performing other tasks on it. If the unit is not properly mounted, it could fall off and cause damage or injury. G You can be injured if you touch the heat exchanger when removing or installing the plasma filter unit. -
Page 13: Troubleshooting
TROUBLESHOOTING In the event of a malfunction (burning smell, etc.), immediately stop operation, disconnect the WARNING! Power Supply Plug, and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source. Always be sure to disconnect the Power Supply Plug or turn off your circuit breaker to ensure that power is completely off. -
Page 14: Operating Tips
TROUBLESHOOTING Symptom Items to check See Page G Is the Power Supply Plug disconnected its outlet? CHECK ONCE Doesn’t operate at all: MORE G Has there been a power failure? — G Has a fuse blown out, or a circuit breaker been tripped? G Is the timer operating? 7 - 8 G Is the air filter dirty? - Page 15 OPERATING TIPS Temperature and Humidity Range Cooling/Dry Mode Heating Mode Outdoor temperature About 32 to 115 °F About 17 to 75 °F Indoor temperature About 64 to 90 °F 88 °F or less About 80% or less If the unit is used for long pe- Outdoor temperature 68°F or obove riods under high-humidity...
