Set System - Qlogic Data Migration Service User Manual

set system

Changes the operational mode of the MPX200 to Data Migration from the default
mode of iSCSI Server Connectivity. All the data migration CLI and GUI features
are activated only in the Data Migration mode. This command removes all
existing mapping-related settings and causes the MPX200 to reboot.
Session
admin
Example
The following example shows the set system command:
MPX200 <1> (admin) #> set system
A list of attributes with formatting and current values will follow.
Enter a new value or simply press the ENTER key to accept the current value.
If you wish to terminate this process before reaching the end of the list
press 'q' or 'Q' and the ENTER key to do so.
A list of attributes with formatting and current values will follow.
Enter a new value or simply press the ENTER key to accept the current value.
If you wish to terminate this process before reaching the end of the list
press 'q' or 'Q' and the ENTER key to do so.
System Symbolic Name (Max = 64 characters)
Target Presentation Mode (0=Auto, 1=Manual)
Controller Lun AutoMap
Target Access Control
Telnet (0=Enable, 1=Disable)
SSH (0=Enable, 1=Disable)
System Log Level (Default,Min=0, Max=2)
All attribute values that have been changed will now be saved.
ISR654606-00 A
(0=Enable, 1=Disable)
(0=Enable, 1=Disable)
5–Command Line Interface
set system
[Blade-1 ]
[Auto ]
[Disabled ]
[Enabled ]
[Enabled ]
[Enabled ]
[0 ]
5-5
