3–Using DMS
Using the Data Migration Wizard
The left pane of the Create Data Migration Job dialog box shows a
DataMigration Job (New) option with icons for Source LUNs and
Destination LUNs.
The right pane of the Create Data Migration Job dialog box shows the type
of array (Source, Destination, or Src+Dest) for each of the arrays available
for configuring the data migration job.
3. Choose the appropriate source and destination LUN for the migration job by
dragging and dropping the LUNs from the right pane onto the Source LUN
or Destination LUN under DataMigration Job (New) in the left pane.
The HP StorageWorks mpx Manager populates the Source LUN and
Destination LUN attributes and creates a new DataMigration Job n (New)
object below the first one. The default job name is created by using the
source and destination array names.
4. Repeat the preceding steps to create migration jobs for all source LUNs to
be migrated in a batch, as shown in
Figure 3-7 Create Data Migration Job: Batch
3-16
Figure 3-7.
ISR654606-00 A
