2–Getting Started

Supported Configurations

Table 2-1. Migration Rates for Single and Dual Blade Configurations

2Gb Fibre Channel

4Gb Fibre Channel

8Gb Fibre Channel

Fabric Configuration

Figure 2-2

availability (HA) configuration with both array controller ports and one port from

each MPX200 blade connected to each fabric. This configuration enables the

MPX200 to perform load balancing.

Single

Blade

Figure 2-2 Single and Dual Blade High Availability Setup

Table 2-1

depending on the bandwidth capability of the storage array.

2-2

Array Type

shows typical setup for data migration with a dual fabric high

shows the migration rates that can be achieved for a single blade,

Single Blade

700 GB/hour

1.25 TB/hour

2 TB/hour

Dual

Blade

Dual Blade

1 TB/hour

2.5 TB/hour

4 TB/hour

ISR654606-00 A
