INSTRUCTION MANUAL
PICTROGRAPHY SERIES
Internal LUT Version Upgrading Procedure/
Plug-in LUT Operating Procedure
First Edition
PP3-B601E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pictrography series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FujiFilm Pictrography series

Summary of Contents for FujiFilm Pictrography series

  • Page 1 INSTRUCTION MANUAL PICTROGRAPHY SERIES Internal LUT Version Upgrading Procedure/ Plug-in LUT Operating Procedure First Edition PP3-B601E...
  • Page 2 INTRODUCTION • This instruction manual explains the operating procedures and precautions for the new LUTs for the PICTROGRAPHY 3500 / 4000 / 4500 / 4500N and the new plug-in LUTs for the PICTROGRAPHY 3000 / 4000 and PICTROSTAT Digital 400. •...

  • Page 3: Table Of Contents

    Contents Purpose of LUT Improvement and Types of New LUT ..........Internal LUT ........................ Plug-in LUT ......................... Internal LUT Version Upgrading Procedure (PICTROGRAPHY 3500 / 4000 / 4500 / 4500N) ..Preparation for Version Upgrade ................2.1.1 Confirmation of Current LUT Version ................2.1.2 Confirmation of Folder Configuration in CD-ROM and Selection of File ......

  • Page 5: Purpose Of Lut Improvement And Types Of New Lut

    Purpose of LUT Improvement and Types of New LUT Internal LUT The LUT for the PICTROGRAPHY 3500 / 4000 / 4500 / 4500N has been improved to sup port a new-type donor. By installing the new LUT into these models, the user can make prints with improved color balance and gray gradation.

  • Page 6: Plug-In Lut

    Plug-in LUT The plug-in LUT for the PICTROGRAPHY 3000 / PICTROGRAPHY 4000 / PICTROSTAT Digital 400 has been improved to support a new-type donor. This new LUT is used for obtaining print results (gradation, color balance and gray balance) similar to conventional ER prints even when using the new donor.

  • Page 7: Internal Lut Version Upgrading Procedure (Pictrography 3500 / 4000 / 4500 / 4500N)

    Internal LUT Version Upgrading Procedure (PICTROGRAPHY 3500 / 4000 / 4500 / 4500N) Preparation for Version Upgrade 2.1.1 Confirmation of Current LUT Version Before installing the new LUT, confirm and write down the version of the LUT currently installed into the PICTROGRAPHY.
  • Page 8 Press the [SEL] key. • The message changes to “PRD Ver.X.XX” (PIC- <PICTROGRAPHY 3500> TROGRAPHY 3500) or “PIC Ver.X.XX” (PIC- TROGRAPHY 4000 / 4500 / 4500N). Ver.X.XX <PICTROGRAPHY 4000 /4500/4500N> Ver.X.XX Press the [NEXT] key. • The message changes to “LUT 3D-LUT”. - 3D-LUT + Press the [SEL] key.

  • Page 9: Confirmation Of Folder Configuration In Cd-Rom And Selection Of File

    2.1.2 Confirmation of Folder Configuration in CD-ROM and Selection of File The program file necessary for installing a LUT varies depending on the purpose of operation, oper- ating system of the host computer, model of the PICTROGRAPHY and connection method. Select an appropriate file in the CD-ROM referring to the following: Windows PICTROGRAPHY 3500...
  • Page 10 PICTROGRAPHY 4000 PGUP.exe PG4000 LUT V300_220 English PGVU_TCP.exe PGUP.exe LUT V300_230 English PGVU_TCP.exe PGUP.exe LUT V300_250 English PGVU_TCP.exe PGUP.exe LUT V300_255 English PGVU_TCP.exe PGUP.exe Firmware LUT V220_220 English PGVU_TCP.exe PGUP.exe LUT V220_230 English PGVU_TCP.exe PGUP.exe LUT V250_255 English PGVU_TCP.exe PGUP.exe English Program PGVU_TCP.exe...
  • Page 11 Purpose of Installation and Selection of Corresponding File (PICTROGRAPHY 4000 ) Purpose of PICTROGRAPHY File Selection Method (“XXX” represents folder name.) Installation Connection Method Upgrading from Old SCSI Connection “PG4000 ” “LUT V300_220” “English” PGUP.exe LUT Ver.2.20 to New LUT Ver.3.00 PNA Connection “PG4000 ”...
  • Page 12 PICTROGRAPHY 4500 PGUP.exe PG4500 LUT V200 English PGVU_TCP.exe PGUP.exe English Firmware LUT V100 PGVU_TCP.exe PGUP.exe Program English PGVU_TCP.exe Folder Configuration related to PICTROGRAPHY 4500 Purpose of Installation and Selection of Corresponding File (PICTROGRAPHY 4500) Purpose of PICTROGRAPHY File Selection Method (“XXX” represents folder name.) InstallationI Connection Method Upgrading to New...
  • Page 13 Macintosh PICTROGRAPHY 3500 PGUP PG3500 LUT V200 English PICTRO Upgrade (AT) PICTRO Upgrade (SCSI) MacOSX PICTRO Upgrade (AT) PGUP Firmware LUT V102 English PICTRO Upgrade (AT) PICTRO Upgrade (SCSI) MacOSX PICTRO Upgrade (AT) PGUP English LUT V104 PICTRO Upgrade (AT) PICTRO Upgrade (SCSI) MacOSX PICTRO Upgrade (AT)
  • Page 14 Purpose of Installation and Selection of Corresponding File (PICTROGRAPHY 3500) OS for PICTROGRAPHY Purpose of Host Connection File Selection Method (“XXX” represents folder name.) Installation Computer Method Upgrading to New Mac OS SCSI Connection “PG3500” “LUT V200” “English” PGUP LUT Ver.2.00 PNA Connection “PG3500”...
  • Page 15 PICTROGRAPHY 4000 PGUP PG4000 LUT V300_220 English PICTRO Upgrade (AT) PICTRO Upgrade (SCSI) MacOSX PICTRO Upgrade (AT) PGUP LUT V300_230 English PICTRO Upgrade (AT) PICTRO Upgrade (SCSI) MacOSX PICTRO Upgrade (AT) PGUP LUT V300_250 English PICTRO Upgrade (AT) PICTRO Upgrade (SCSI) MacOSX PICTRO Upgrade (AT) PGUP...
  • Page 16 Purpose of Installation and Selection of Corresponding File (PICTROGRAPHY 4000 ) OS for PICTROGRAPHY Purpose of Host Connection File Selection Method (“XXX” represents folder name.) Installation Computer Method Upgrading from Old LUT Mac OS SCSI Connection “PG4000 ” “LUT V300_200” “English”...
  • Page 17 PICTROGRAPHY 4500 PGUP PG4500 LUT V200 English PICTRO Upgrade (AT) PICTRO Upgrade (SCSI) MacOSX PICTRO Upgrade (AT) PGUP Firmware LUT V100 English PICTRO Upgrade (AT) PICTRO Upgrade (SCSI) MacOSX PICTRO Upgrade (AT) PGUP English Program PICTRO Upgrade (AT) PICTRO Upgrade (SCSI) MacOSX PICTRO Upgrade (AT) Folder Configuration related to PICTROGRAPHY 4500...
  • Page 18 PICTROGRAPHY 4500N PICTRO Upgrade (AT) PG4500N LUT V200 English PICTRO Upgrade (AT) MacOSX PICTRO Upgrade (AT) English Firmware LUT V100 PICTRO Upgrade (AT) MacOSX PICTRO Upgrade (AT) Program English PICTRO Upgrade (AT) MacOSX Folder Configuration related to PICTROGRAPHY 4500N Purpose of Installation and Selection of Corresponding File (PICTROGRAPHY 4500N) Purpose of OS for Host File Selection Method (“XXX”...

  • Page 19: Internal Lut Version Upgrading Procedure

    Internal LUT Version Upgrading Procedure The internal LUT can be upgraded using the version upgrading utility on the host computer (Windows or Macintosh) connected to the PICTROGRAPHY 3500 / 4000 / 4500 / 4500N. 2.2.1 Windows + SCSI Connection (PICTROGRAPHY 3500 / 4000 / 4500) •...
  • Page 20 Double-click the CD-ROM icon to open the CD-ROM. • All folders stored on the CD-ROM appear. By referring to Subsection 2.1.2, double- click the “PGUP.exe” file appropriate for the purpose of installation. • A dialog box to start the program appears. Click the [OK] button.
  • Page 21 Click the [OK] button. • Version upgrade starts and the dialog box shown at the left appears. • The LCD screen of the PICTROGRAPHY 3500 / VersionUP 4000 / 4500 becomes as shown at the left. Installing • If you click the [Cancel] button, a dialog box appears, asking if you really want to stop version upgrading.Click the [OK] button to stop or click the [Cancel] button to continue upgrading.
  • Page 22 Click the [OK] button. Version upgrade is now completed. Note : Do not execute multiple [PGUP.exe] files • at the same time. Do not drag a dialog during version • upgrade.

  • Page 23: Windows + Pna Connection (Pictrography 3500 / 4000 / 4500)

    2.2.2 Windows + PNA Connection (PICTROGRAPHY 3500 / 4000 / 4500) • Examples of PICTROGRAPHY 4500 are used in the procedure below. Turn ON the power for the PICTROGRA- PHY 3500 / 4000 / 4500. Note : If an error occurs during start-up, take the following steps.
  • Page 24 Double-click the CD-ROM icon to open the CD-ROM. • All folders stored on the CD-ROM appear. By referring to Subsection 2.1.2, double- click the “PGVU_TCP.exe” file appropriate for the purpose of installation. • A dialog box to start the program appears. Click the [OK] button.
  • Page 25 Enter the IP address of the PNA and then click the [OK] button. • A dialog box listing the available versions Version After Installation Current Version appears. Click the [OK] button. • Version upgrade starts and the dialog box shown at the left appears. •...
  • Page 26 Error Message Cause • Defective communications. PICTROGRAPHY not found. • PNA is not connected. • Incorrect IP address is entered. No version updating data available. • No PG program file or LUT file is present in the specified folder. PICTROGRAPHY not ready. •...

  • Page 27: Macos + Scsi Connection (Pictrography 3500 / 4000 / 4500)

    2.2.3 MacOS + SCSI Connection (PICTROGRAPHY 3500 / 4000 / 4500) • Examples of PICTROGRAPHY 4500 are used in the procedure below. Turn ON the power for the PICTROGRA- PHY 3500 / 4000 / 4500. Note : If an error occurs during start-up, take the following steps.
  • Page 28 Double-click the CD-ROM icon to open the CD-ROM. • All folders stored on the CD-ROM appear. By referring to Subsection 2.1.2, double- click the “PGUP” file appropriate for the purpose of installation. • A dialog box to start the program appears. Click the [OK] button.
  • Page 29 Click the [OK] button. • Version upgrade starts and the dialog box shown at the left appears. • The LCD screen of the PICTROGRAPHY 3500 / VersionUP 4000 / 4500 becomes as shown at the left. Installing • If you click the [Cancel] button, a dialog box appears, asking if you really want to stop version upgrading.
  • Page 30 Click the [OK] button. Version upgrade is now completed. Note : Be sure to start the “PGUP” file from the CD-ROM (do not start it from a hard disk onto which the contents of the CD-ROM are copied.)

  • Page 31: Macos + Pna Connection (Pictrography 3500 / 4000 / 4500)

    2.2.4 MacOS + PNA Connection (PICTROGRAPHY 3500 / 4000 / 4500) • Examples of PICTROGRAPHY 4500 are used in the procedure below. Turn ON the power for the PICTROGRA- PHY 3500 / 4000 / 4500. Note : If an error occurs during start-up, take the following steps.
  • Page 32 • The CD-ROM named “PGSys” is mounted. Check that the PICTROGRAPHY 3500 / 4000 / 4500 is in the [Data Ready (except during print ejection)] state. Double-click the CD-ROM icon to open the CD-ROM. • All folders stored on the CD-ROM appear. By referring to Subsection 2.1.2, double- click the “PICTRO Upgrade (AT)”...
  • Page 33 Click the [OK] button. • A dialog box for printer selection appears. Note : The name displayed in the “Printer” col- umn varies depending on the PNA because it is the AppleTalk printer name set to the PNA. Click the displayed PNA and then click Version After the [Next] button.
  • Page 34 • The LCD screen of the PICTROGRAPHY 3500 / VersionUP 4000 / 4500 becomes as shown at the left. Installing • If you click the [Cancel] button, a dialog box appears, asking if you really want to stop version upgrading. Click the [OK] button to stop or click the [Cancel] button to continue upgrading. •...

  • Page 35: Macosx + Scsi Connection (Pictrography 3500 / 4000 / 4500)

    2.2.5 MacOSX + SCSI Connection (PICTROGRAPHY 3500 / 4000 / 4500) • Examples of PICTROGRAPHY 4500 are used in the procedure below. Turn ON the power for the PICTROGRA- PHY 3500 / 4000 / 4500. Note : If an error occurs during start-up, take the following steps.
  • Page 36 Double-click the CD-ROM icon to open the CD-ROM. • All folders stored on the CD-ROM appear. By referring to Subsection 2.1.2, double- click the “PICTRO Upgrade (SCSI)” file appropriate for the purpose of installa- tion. • A dialog box to start the program appears. Click the [Next] button.
  • Page 37 Click the [Next] button. • Version upgrade starts and the dialog box shown at the left appears. • The LCD screen of the PICTROGRAPHY 3500 / VersionUP 4000 / 4500 becomes as shown at the left. Installing • If you click the [Cancel] button, a dialog box appears, asking if you really want to stop version upgrading.
  • Page 38 Click the [OK] button. Version upgrade is now completed. Note : Be sure to start the “PICTRO Upgrade (SCSI)” file from the CD-ROM (do not start it from a hard disk onto which the contents of the CD-ROM are copied.)

  • Page 39: Macosx + Pna Connection (Pictrography 3500 / 4000 / 4500)

    2.2.6 MacOSX + PNA Connection (PICTROGRAPHY 3500 / 4000 / 4500) • Examples of PICTROGRAPHY 4500 are used in the procedure below. Turn ON the power for the PICTROGRA- PHY 3500 / 4000 / 4500. Note : If an error occurs during start-up, take the following steps.
  • Page 40 • The “System Preferences” dialog box appears. Click the [Network] icon. • The “Network” dialog box appears. Click the [AppleTalk] tab. • The dialog box changes as shown at the left. Check the [Make AppleTalk Active] checkbox and then close the [Network] dialog box.
  • Page 41 Double-click the CD-ROM icon to open the CD-ROM. • All folders stored on the CD-ROM appear. By referring to Subsection 2.1.2, dou- ble-click the “PICTRO Upgrade (AT)” file appropriate for the purpose of installation. • A dialog box to start the program appears. Click the [Next] button.
  • Page 42 Click the displayed PNA and then click the [Next] button. Version After Current Version Installation • A dialog box listing the available versions appears. Click the [Next] button. • Version upgrade starts and the dialog box shown at the left appears. •...
  • Page 43 • If you click the [Cancel] button, a dialog box appears, asking if you really want to stop version upgrading. Click the [OK] button to stop or click the [Cancel] button to continue upgrading. • If an error occurs, an error message dialog box appears. Confirm the error cause and perform ver- sion upgrade again.

  • Page 44: Windows + Pictrography 4500N

    2.2.7 Windows + PICTROGRAPHY 4500N Turn ON the power for the PICTROGRA- PHY 4500N. Note : If an error occurs during start-up, take the following steps. • If an error appears on the LCD, press the ] key. • The [Version Up?] message appears on the LCD.
  • Page 45 By referring to Subsection 2.1.2, double- click the “PGVUEN.exe” file appropriate for the purpose of installation. • A dialog box to start the program appears. Click the [OK] button. • A dialog box for entering the IP address appears. (When the IP address of the PNA is 192.168.1.80) Enter the IP address of the PICTROGRA- PHY 4500N and then click the [OK] button.
  • Page 46 Click the [OK] button. • Version upgrade starts and the dialog box shown at the left appears. • The LCD screen of the PICTROGRAPHY VersionUP 4500N becomes as shown at the left. Installing • If you click the [Cancel] button, a dialog box appears, asking if you really want to stop version upgrading.
  • Page 47 Click the [OK] button. Version upgrade is now completed. Note : Do not execute multiple [PGVUEN.exe] • files at the same time. Do not drag a dialog during version • upgrade.

  • Page 48: Macos + Pictrography 4500N

    2.2.8 MacOS + PICTROGRAPHY 4500N Turn ON the power for the PICTROGRA- PHY 4500N. Note : If an error occurs during start-up, take the following steps. • If an error appears on the LCD, press the ] key. • The [Version Up?] message appears on the LCD.
  • Page 49 Check that the PICTROGRAPHY 4500N is in the [Data Ready (except during print ejection)] state. Double-click the CD-ROM icon to open the CD-ROM. • All folders stored on the CD-ROM appear. By referring to Subsection 2.1.2, double- click the “PICTRO Upgrade (AT)” file appropriate for the purpose of installa- tion.
  • Page 50 • A dialog box for printer selection appears. Note : The name displayed in the “Printer” col- umn varies depending on the PNA because it is the AppleTalk printer name set to the PICTROGRAPHY 4500N. Version After Click the displayed PICTROGRAPHY Current Version Installation 4500N and then click the [Next] button.
  • Page 51 • The LCD screen of the PICTROGRAPHY VersionUP 4500N becomes as shown at the left. Installing • If you click the [Cancel] button, a dialog box appears, asking if you really want to stop version upgrading. Click the [OK] button to stop or click the [Cancel] button to continue upgrading. •...

  • Page 52: Macosx + Pictrography 4500N

    2.2.9 MacOSX + PICTROGRAPHY 4500N Turn ON the power for the PICTROGRA- PHY 4500N. Note : If an error occurs during start-up, take the following steps. • If an error appears on the LCD, press the ] key. • The [Version Up?] message appears on the LCD.
  • Page 53 Click the [Network] icon. • The “Network” dialog box appears. Click the [AppleTalk] tab. • The dialog box changes as shown at the left. Check the [Make AppleTalk Active] checkbox and then close the [Network] dialog box. Insert the CD-ROM in the host computer. •...
  • Page 54 By referring to Subsection 2.1.2, dou- ble-click the “PICTRO Upgrade (AT)” file appropriate for the purpose of installation. • A dialog box to start the program appears. Click the [Next] button. • A dialog box for printer selection appears. Note : The name displayed in the “Printer” col- umn varies depending on the PNA because it is the AppleTalk printer name set to the PICTROGRAPHY 4500N.
  • Page 55 Click the displayed PICTROGRAPHY 4500N and then click the [Next] button • A dialog box listing the available versions Version After Current Version Installation appears. Click the [Next] button. • Version upgrade starts and the dialog box shown at the left appears. •...
  • Page 56 • If you click the [Cancel] button, a dialog box appears, asking if you really want to stop version upgrading. Click the [OK] button to stop or click the [Cancel] button to continue upgrading. • If an error occurs, an error message dialog box appears. Confirm the error cause and perform ver- sion upgrade again.

  • Page 57: Operation After Version Upgrade

    Operation After Version Upgrade When the LUT or program installation is completed, turn the power switch OFF and ON. After installing the LUT, perform calibration referring to Chapter 4 (PICTROGRAPHY 4000 / 4500 / 4500N) or Chapter 5 (PICTROGRAPHY 3500) of the Instruction Manual. After program installation, a “Service”...

  • Page 58: Plug-In Lut Operating Procedure

    Plug-in LUT Operating Procedure (PICTROGRAPHY 3000 / 4000 / PICTROSTAT DIGITAL 400) The LUT setting function is available for the following versions of Photoshop Plug-in. • MacOS MacOSX Windows PICTROGRAPHY 4000 2.2.0 1.0.1 2.20 PICTROGRAPHY 3000 1.2.0 1.0.2 1.20 PICTROSTAT DIGITAL 400(Print) 1.2.0 1.20 Note : PSD400 Plug-in cannot be used for MacOSX.
  • Page 59 Click the [Load] button to specify the LUT for new donor. Select the appropriate LUT referring to <LUT Locations in the CD-ROM> the figure shown at the left. PG3000.PGLut PG3000 Plug-inLUT PG3000.PGLut PG4000ON1.PGLut PG4000 Plug-inLUT PG4000ON2.PGLut PG4000ON3.PGLut PSD400ON1.PGLut PSD400 Plug-inLUT PSD400ON2.PGLut •...

  • Page 60: Macosx

    3.1.2 MacOSX • Examples of PICTROGRAPHY 4000 are used in the procedure below. Check the “LUT” checkbox and then click the [LUT Settings] button. • The dialog box shown at the left appears. Click the [Load] button to specify the LUT for new donor.
  • Page 61 Select the appropriate LUT referring to <LUT Locations in the CD-ROM> the figure shown at the left. PG3000 PG3000 Plug-inLUT MacOS PG3000 MacOSX PG4000ON1 PG4000 Plug-inLUT MacOS PG4000ON2 PG4000ON1 MacOSX PG4000ON2 PG4000ON3 PSD400ON1 PSD400 Plug-inLUT MacOS PSD400ON2 • The selected LUT is loaded. Click the [OK] button.

  • Page 62: Functions On The "Lut Settings" Screen

    Functions on the “LUT Settings” Screen 3.2.1 Windows • Examples of PICTROGRAPHY 4000 are used in the procedure below. The Y-axis of dialog box’s graphic area will be the input data and the X-axis will be the output data, 0% for black color and 100% for white color.
  • Page 63 [Reset] Button • By clicking on the [Reset] button, the tone curve will be reset to the default value. If the “RGB Separated” option is checked, only the selected tone curve will be reset to the default value. [Save] Button •...

  • Page 64: Macosx

    3.2.2 MacOSX • Examples of PICTROGRAPHY 4000 are used in the procedure below. The Y-axis of dialog box’s graphic area will be the input data and the X-axis will be the output data, 0% for black color and 100% for white color. There are 13 fiducial points within the graphic area.
  • Page 65 [Reset] Button • By clicking on the [Reset] button, the tone curve will be reset to the default value. If the “RGB Separated” option is checked, only the selected tone curve will be reset to the default value. [Save] Button •...
  • Page 66 FAX ; 81-3-5484-0454 Questionaire concerning This Manual Fujifilm’s Technical Division Photo Products Marketing would be most grateful if you would take copies of this form, one for each manual being used, then complete and send them to us by FAX. Your opinions will contribute greatly to an accurate assessment of the overall quality of each manual.
  • Page 67 FUJI PHOTO FILM CO., LTD. 26-30, Nishiazabu 2-chome, Minato-ku, Tokyo 106-8620, Japan. Printed on Recycled Paper Ref.No.PP3-B601E TD-04.09-FG Printed in Japan...
