Grizzly H8093 Specifications

Failure to follow these instructions could
result in serious personal injury or death:
1. DO NOT overload this jack beyond its
rated capacity. Overloading can cause
the jack to collapse and drop the load.
2. ALWAYS support the vehicle with appro-
priately rated support stands before
working under it.
3. DO NOT attempt to move the vehicle
while the jack is in use.
4. Use only on hard level surfaces like
concrete or asphalt. Other surfaces are
potentially unstable.
5. Center the load on the jack to maintain
proper balance and stability.
6. DO NOT use jack if it begins leaking
fluid or if it sinks when placed under
load. These are indications that the jack
needs to be immediately serviced.

Specifications

Maximum Lifting Capacity ................... 5000 Lbs.
Lifting Range ......................................3
Weight ................................................... 108 Lbs.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ "–15
3 1
8
COPYRIGHT © DECEMBER, 2006 BY GRIZZLY INDUSTRIAL, INC.
#TR8824 PRINTED IN CHINA
Model H8093
2 ⁄ Ton Low Profile
1
2
Garage Jack
Operation
To raise the jack, rotate the pump valve knob
clockwise completely, then move the pump han-
dle or foot pump up and down. To lower the jack,
slowly rotate the pump valve knob counterclock-
wise.
Foot
Pump
⁄ "
16
If you need help with the Model H8093, call our
Technical Support line at: (570) 546-9663.
Pump Valve
Knob
Pump
Handle
Figure 1. Jack controls.
