Parts and Service
Manual Supplement
Welder
Part No. 106730
Rev A1
April 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 106730 and is the answer not in the manual?

Questions and answers

Related Manuals for Lincoln Electric 106730

Summary of Contents for Lincoln Electric 106730

  • Page 1 Parts and Service Part No. 106730 Rev A1 Manual Supplement April 2006 Welder...
  • Page 2 Genie policy. Therefore, product specifications are subject to change without notice. Readers are encouraged to notify Genie of errors and send in suggestions for improvement. All communications will be carefully considered for future printings of this and all other manuals.

  • Page 3: Table Of Contents

    If you have a printed manual, you can keep it up to date by downloading new figures from the Genie website. To learn about the benefits Genie eBusiness customers receive, visit the Genie Industries website at www.genieindustries.com and select Parts & Service.
  • Page 4 April 2006 This page intentionally left blank. Welder Supplement Part No. 106730...

  • Page 5: Safety Rules

    100 • Parts April 2006 Safety Rules Danger Failure to obey the instructions and safety rules in the Lincoln Electric Invertec™ V275-S Operator’s Manual will result in death or serious injury. Many of the hazards identified in the operator’s manual are also safety hazards when maintenance and repair procedures are performed.

  • Page 6: And S-45 Chassis Components, Engine Side

    100 • Parts April 2006 Figure Description 101.1 S-40 and S-45 Chassis Components, Engine Side 36 31 32 33 34 35 30 31 32 Welder Supplement Part No. 106730...

  • Page 7: Squeeze Connector

    100 • Parts April 2006 101.1 S-40 and S-45 Chassis Components, Engine Side Rev A Item Part No. Description Qty. Item Part No. Description Qty. 82237 Decal - Danger, High Voltage ..2 106073 Circuit Breaker, 20A, Single Phase ........ 1 106113 Hydraulic Generator Assembly (includes item 38) ......

  • Page 8: And S-65 Chassis

    100 • Parts April 2006 Figure Description 102.1 S-60 and S-65 Chassis Components 25 26 27 22 23 23 24 21 12 13 17 18 Welder Supplement Part No. 106730...

  • Page 9: The Following Components Are Located In The Ground

    100 • Parts April 2006 102.1 S-60 and S-65 Chassis Components Rev A Item Part No. Description Qty. Item Part No. Description Qty. 82237 Decal - Danger, High Voltage ..2 6888 Screw - HHC, -20 x 1 inch, GR 5 106113 Hydraulic Generator Assembly 6638...

  • Page 10: Chassis Components

    100 • Parts April 2006 Figure Description 103.1 Z-60 Chassis Components 11 12 13 Welder Supplement Part No. 106730...
  • Page 11 100 • Parts April 2006 103.1 Z-60 Chassis Components Rev A Item Part No. Description Qty. Item Part No. Description Qty. 102314 Enclosure Panel ......1 106415 Generator Mount Bracket, Bottom .......... 1 36294 Screw - HHC, 1/4 -20 x 2.75 inches, GR 5 106184 Hydraulic Motor, 21cc ....

  • Page 12: And Z-80 Chassis

    100 • Parts April 2006 Figure Description 104.1 S-80, S-85 and Z-80 Chassis Components 34 35 35 36 31 32 33 29 30 4 25 26 27 28 Welder Supplement Part No. 106730...

  • Page 13: Check Valve, 3 Psi / 0.2 Bar Solenoid Valve, 10V Dc Coil, 10V Dc Gr

    100 • Parts April 2006 104.1 S-80, S-85 and Z-80 Chassis Components Rev A Item Part No. Description Qty. Item Part No. Description Qty. 106184 Hydraulic Motor, 21cc ....1 106077 Squeeze Connector, 0.63 - 0.75 inch ..........1 106113 Hydraulic Generator Assembly (includes item 1) ......

  • Page 14: Platform Components, All Models

    100 • Parts April 2006 Figure Description 105.1 Platform Components, all Models Welder Supplement Part No. 106730...
  • Page 15 100 • Parts April 2006 105.1 Platform Components, all Models Rev B Item Part No. Description Qty. — 88406 Fire Extinguisher — 82862 Decal - Fire Extinguisher — 97579 Decal - Danger, Tip-over (located on Decal Plate) — 32728 Decal, Generator (located on Platform Control Panel) 106112 Plug, 4 Wire, 3-Phase, 50A ..
  • Page 16 E2 NOT USED CR46 E3 NOT USED E3 NOT USED Add three Genie P/N 45762 6 amp 200 PIV diodes in Add three Genie P/N 45762 6 amp 200 PIV diodes in F1 DIG IN 0 F1 DIG IN 0 the position shown in the schematic.
  • Page 17 July 2004 200 • Schematics and Hose Drawings Figure Description 201.1 Electrical Schematic...

  • Page 19: And S-65 Hoses And Fittings

    200 • Schematics and Hose Drawings July 2004 Figure Description 202.1 S-60 and S-65 Hoses and Fittings FUNCTION DRIVE PUMP MANIFOLD PMP B PMP A WELDER MANIFOLD LEGEND FITTING 0.031 HOSE ASSEMBLY CONNECTOR 270 PSI @ 3.5 GPM 21 GPM MTR B MTR A HYDRAULIC...
  • Page 20 Fitting ..........1 48948 Fitting ..........1 61610 Fitting ..........1 The length listed in the component description is the length of the hose only. Refer to 207.1 to cross-reference Genie part numbers to Parker part numbers. Part No. 106730 Welder Supplement...

  • Page 21: And S-45 Hoses And Fittings

    200 • Schematics and Hose Drawings July 2004 Figure Description 203.1 S-40 and S-45 Hoses and Fittings FUNCTION DRIVE PUMP MANIFOLD PMP B PMP A WELDER MANIFOLD LEGEND FITTING 0.031 HOSE ASSEMBLY CONNECTOR 270 PSI @ 3.5 GPM 21 GPM MTR B MTR A HYDRAULIC...
  • Page 22 Fitting ..........1 48948 Fitting ..........1 48958 Fitting ..........2 The length listed in the component description is the length of the hose only. Refer to 207.1 to cross-reference Genie part numbers to Parker part numbers. Part No. 106730 Welder Supplement...

  • Page 23: And S-85 Hoses And Fittings

    200 • Schematics and Hose Drawings July 2004 Figure Description 204.1 S-80 and S-85 Hoses and Fittings FUNCTION DRIVE PUMP MANIFOLD PMP B PMP A WELDER MANIFOLD LEGEND FITTING 0.031 HOSE ASSEMBLY CONNECTOR 270 PSI @ 3.5 GPM 21 GPM MTR B MTR A HYDRAULIC...
  • Page 24 Fitting ..........1 48948 Fitting ..........1 48958 Fitting ..........2 The length listed in the component description is the length of the hose only. Refer to 207.1 to cross-reference Genie part numbers to Parker part numbers. Part No. 106730 Welder Supplement...

  • Page 25: Z-60/34 Hoses And Fittings

    200 • Schematics and Hose Drawings July 2004 Figure Description 205.1 Z-60/34 Hoses and Fittings FUNCTION DRIVE PUMP MANIFOLD PMP B PMP A WELDER MANIFOLD LEGEND FITTING 0.031 HOSE ASSEMBLY CONNECTOR 270 PSI @ 3.5 GPM 21 GPM MTR A MTR B HYDRAULIC SUCTION...
  • Page 26 48818 and 48751 @ 82 inches ... 1 48875 Fitting ..........1 48948 Fitting ..........1 The length listed in the component description is the length of the hose only. Refer to 207.1 to cross-reference Genie part numbers to Parker part numbers. Part No. 106730 Welder Supplement...

  • Page 27: Z-80/60 Hoses And Fittings

    200 • Schematics and Hose Drawings July 2004 Figure Description 206.1 Z-80/60 Hoses and Fittings FUNCTION DRIVE PUMP MANIFOLD PMP B PMP A WELDER MANIFOLD LEGEND FITTING 0.031 HOSE ASSEMBLY CONNECTOR 270 PSI @ 3.5 GPM 21 GPM MTR B MTR A HYDRAULIC SUCTION...
  • Page 28 @ 110 inches ....... 1 48935 Fitting ..........1 48958 Fitting ..........2 The length listed in the component description is the length of the hose only. Refer to 207.1 to cross-reference Genie part numbers to Parker part numbers. Part No. 106730 Welder Supplement...
  • Page 29 200 • Schematics and Hose Drawings July 2004 Figure Description 207.1 Hydraulic Hose and Fitting Cross-reference Genie PN Parker PN Description Genie PN Parker PN Description 12342 6-4 F5OX-S CONNECTOR,STRAIGHT THREAD TO FLARE TUBE 42794 1 CR-S ELBOW,90º,MALE PIPE 13757...
  • Page 30 200 • Schematics and Hose Drawings July 2004 207.1 Hydraulic Hose and Fitting Cross-reference Rev A Genie PN Parker PN Description Genie PN Parker PN Description 48813 1J143-6-6 HOSE END,90º FEMALE SWIVEL,SEAL LOK 48875 6 R6LO-S RUN TEE,SWIVEL NUT,ORFS 48814 1J543-6-6 HOSE END,90º...
  • Page 31 200 • Schematics and Hose Drawings July 2004 Figure Description 207.1 Hydraulic Hose and Fitting Cross-reference Genie PN Parker PN Description Genie PN Parker PN Description 48919 6 S5OLO-S BRANCH TEE,STRAIGHT THREAD TO ORFS 48968 12 WLO-WLNL-S UNION,BULKHEAD,ORFS 48920 6 V5OLO-S ELBOW,45º,STRAIGHT THREAD TO ORFS...
  • Page 32 200 • Schematics and Hose Drawings July 2004 207.1 Hydraulic Hose and Fitting Cross-reference Rev A Genie PN Parker PN Description Genie PN Parker PN Description 49519 16-12 F5OLO-S CONNECTOR,STRAIGHT THREAD TO ORFS 54428 8M18C87OMLO-S ELBOW, 90º METRIC, STRAIGHT THREAD TO ORFS...
  • Page 33 200 • Schematics and Hose Drawings July 2004 Figure Description 207.1 Hydraulic Hose and Fitting Cross-reference Genie PN Parker PN Description Genie PN Parker PN Description 61259 4 CC5OLO-S ELBOW,90º LONG,STRAIGHT THREAD TO ORFS 73437 61C-4 NUT,COMPRESSION 61260 20-12 TRLO-BL...
  • Page 34 200 • Schematics and Hose Drawings July 2004 207.1 Hydraulic Hose and Fitting Cross-reference Rev A Genie PN Parker PN Description Genie PN Parker PN Description 83057 33782-6-6 HOSE END,45º FEMALE SWIVEL,JIC 88939 1J988-16-16 HOSE END,90º FEMALE SWIVEL,ORFS 83058 33982-6-6 HOSE END,90º...
