Important Safety Instructions The lightning flash with an arrowhead symbol, within the equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to cause an electric shock. The exclamation point within the equilateral triangle is WARNING: TO REDUCE THE RISK OF ELECTRIC intended to alert the user to the presence of important...
Important Safety Instructions 1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated. 2. Retain Instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to. 4.
Table of Contents Special Functions ......... 25-27 Display function (DVD) .......... 25 GOTO function (DVD) ........... 25 IMPORTANT Locating a specific title ......... 26 Locating a specific title/chapter/track ....26 This Unit does NOT allow Locating a specific time ......... 27 copying from DVD to VCR tape Angle setting ............
Page 5
Table of Contents Adding Channel Memory/Erasing Channel Radio Operation ......... 62 Memory ..............47 Tuning into a station manually ....... 62 Clock ..............48-50 FM Stereo ............. 62 Auto Clock Setting ..........48 Weak FM stations ..........62 Manual Clock Setting ......... 49 To search for a station automatically ....
Disc Formats The Unit can playback. DVDs [8cm(3")/12cm(5”) disc] Compatible Audio CDs [8cm(3")/12cm(5”) disc] Region Management Information Region Management Information: This Unit is designed and manufactured to respond to the Region Management Information that is encoded on DVD discs. If the Region number printed on the DVD disc does not correspond to the Region number of this Unit, this Unit cannot play that disc.
Parts and Functions Front Panel 1) MAIN POWER/ STANDBY button a few seconds. If you press the POWER button on the remote control, the Unit will turn off and go into Turn the power on or off. standby mode. The light will continue to illuminate. STOP button (for VCR) 14) VCR POWER/TIMER/VCR/REC indicator Stop playing a disc.
Parts and Functions Rear Panel 21 22 23 24 25 26 27 28 FM A N T. 3 0 0 ( ) A U DI O LO O P A N T. V ID EO O UT V H F /U H F/ C A TV 21) Power cord 30) AM LOOP ANTENNA terminal...
Parts and Functions Remote Control 1) POWER / button Turns the Unit on and puts it in standby mode. 2) RETURN button Return to the normal operation after using the SETUP menu. 3) Number (0 - 9) and AM/PM (+10) buttons O P E N / P O W E R C LO S E...
Page 10
Parts and Functions Remote Control 21) FUNCTION button Display the FUNCTION screen where you can check or change various setting. 22) OPEN / CLOSE button (for DVD) Use to open or close the disc tray. O P E N / 23) GOTO button P O W E R C LO S E...
Display Front Panel Display ANGLE indicator MEMORY CHAPTER / TRACK indicator REPEAT 1 Appears when multiple camera angles indicator When a DVD is loaded in the playback are recorded in the section of the DVD Displayed Unit, this indicator appears indicator that is currently playing.
Connections 1. Connecting to your TV The Unit can be connected to your TV in several different ways, depending on the design of your TV. 1. Connect the TV antenna (coaxial cable) to the input jack on the unit. 2. Attach one end of the supplied coaxial cable to the output jack on the unit, and the other end of the cable to the input jack on your TV.
Connections Cable TV Connections Your VCR is capable of receiving the following non-scrambled channels. • Scrambled channels can be received with the cable box supplied by your cable TV company. Preparation Set the 3 4 Output Channel of the VCR to 3 or 4. See Setting the 3 4 Output Channel.
Page 14
Connections Connection with cable box 1. Connect as shown. With this connection, it is possible to record descrambled CATV signals. Then plug in the power cords of the TV and cable box. Rear of Unit Cable Box Coaxial cable (Not supplied) TV Rear From CATV...
Page 15
Connections Connection with cable box, A/B switch and splitter By using an A/B switch or splitter, it is possible to switch between the cable box and the VCR output. For example, while recording a TV programme with the VCR, it is possible to watch a CATV programme (including descrambled programmes) using the A/B switch.
Connections Connection with two cable boxes, A/B switch and splitter The following connection is necessary to record a cable TV programme (even those scrambled by a cable company) while watching another cable TV programme. The following connection requires two cable boxes, a 2- way splitter and an A/B switch.
Connections 3. Connecting the speakers & subwoofer 1. The speaker cords have been color-coded to simplify connection. Just plug the POSITIVE (+) and NEGATIVE (-) ends of each speaker wire into the corresponding jacks on the rear of the Unit, matching the color tube on the end of the speaker wire to the color-coded connector.
Connections 5. Connecting Other Equipment You can connect other audio and/or video equipment to your unit in different ways. The following illustrations give a few examples of the connection possibilities. Front of Unit Rear of Unit (Red) (Red) AUDIO (White) (White) Camcorder (Yellow)
Connections Mounting rear surround speakers 1) Mark the correct mounting position on the wall. 2) Insert a fixing screw(s) at the marked position on the wall. 3) Align the slot hole(s) of the speaker over the screw and pull the speaker downward until it is firmly hooked. Need More Help? DO NOT RETURN THIS TO THE STORE Please call Customer Service at 1-800-252-6123...
Adjusting the Sound To adjust the surround sound balance while Pro Logic decoding is in effect Use the remote control to make the following changes to speaker balance: Front speaker (left) • Press the SOUND button repeatedly to display LEFT, then press the CURSOR button to adjust the sound level.
Page 21
Adjusting the Sound To select the listening channel 1. When the disc is stopped, you can press 5.1 CH and 2.1 CH buttons on the remote control to select different speakers output status shown as below table. 2. You can active or off subwoofer output by setup menu. Note: The wording "2.1 CH"...
Playing a Disc Basic playback This owner’s manual explains the basic instructions of this Unit. Some DVD discs are produced in a manner that allows specific or limited operation during playback. As such, the Unit may not respond to all operating commands. This is not a defect in the Unit. Refer to the instruction notes of discs.
Playing a Disc Fast Forward/Fast Reverse 1. Press the TUNING TUNING button when a disc is playing. • The disc begins fast scan at x2 speed. • Four speeds are available. Each time TUNING TUNING button is pressed, the speed of fast scan changes in the following sequence: Note : You also can press and hold...
Playing a Disc Angle selection Some DVDs contain scenes which have been shot from a number of different angles. For these discs, the same scene can be viewed from each of these different angles. 1. While you are playing a DVD with different angles recorded, press the ANGLE button to view the number of the current angle.
Playing a Disc Subtitle selection 1. While a DVD is playing, press the SUBTITLE button to display the current language setting, as shown in the example below. 2. Press the SUBTITLE button repeatedly to select the desired subtitle language. Notes : •...
Special Functions Basic playback DISPLAY function Using DISPLAY, you can check and change the current settings of the following items: ANGLE, AUDIO and SUBTITLE. • While the disc is playing, press the DISPLAY button to display the screen shown below. Elapsed time: Elapsed time from the beginning of the chapter which is currently playing.
Special Functions Basic playback Locating a specific title If a DVD disc contains title numbers, you can locate a specific title by directly selecting a title number. 1. In stop mode, press the GOTO button. 2. Press button to highlight a specific field and press the corresponding number button(s) for the title you want.
Special Functions Basic playback Locating a specific time You can move to a specific location by entering its corresponding time (hours, minutes, seconds) 1. Press the GOTO button. 2. Press button to highlight time. 3. Press the corresponding number buttons for the setting point you want. •...
Advanced CD / DVD programmable memory playback Programmable memory The two types of programmed playback provided by this Unit are title programmed playback and chapter programmed playback. Title / Chapter programmed playback 1.Press the MEMORY button while the disc is stopped. 2.Enter the title numbers in .
Advanced Repeat Playback playback You can play a specific title or chapter repeatedly. (Title repeat, chapter repeat, A-B repeat) Repeating a title You can play the same title repeatedly. 1. While the disc is playing, press the REPEAT DISC button until the “...
Advanced Repeat Playback playback Repeating a specific section You can play a specific section repeatedly. 1. While the disc is playing, press the REPEAT A-B button at the beginning of the section ( ) is displayed you want to play repeatedly.
Playing MP3 and Picture File Disc This Unit will play MP3 and Picture files recorded on CD-R and CD-RW discs Playing a MP3 file disc 1. Press the OPEN /CLOSE button, the disc tray opens. 2. Insert a MP3 file disc on the disc tray with the label side up. 3.
Playing MP3 and Picture File Disc Playing a Picture file disc 1. Press the OPEN /CLOSE button, the disc tray opens. 2. Insert a Picture CD on the disc tray with the label side up. 3. Press the OPEN/CLOSE button, the disc tray closes. 4.
