CARE & INSTRUCTIONS MANUAL INDUCTION COOKTOP • IFA-90 AL Note: To avoid accident and damage, please read these instructions carefully before operating the appliance. -
Page 2: Cooking Hob
GUIDE TO INSTALLATION AND USE Cooking Hob IMPORTANT : Save this manual for the local electrical inspector’s use. INSTALLER: Please leave this manual with the unit for the owner. OWNER: Please keep this manual for future reference. IMPORTANT: Local codes vary. Installation, electrical connections and grounding must comply with all applicable codes. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1 - Proper Installation - Be sure your appliance is properly grounded and installed by a qualified technician. 2 - Never Use your Appliance for Warming or Heating the Room. 3 - Do Not Leave Children Alone - Children should not be left alone or unattended in an area where appliance is in use. - Page 4 Some cleaners can produce noxious fumes if applied to a hot surface. CAUTION Do not store items of interest to children in cabinets above or around the cooktop - children climbing on the cooktop to reach items, could be seriously injured.
-
Page 5: Troubleshooting
Before I I nstallation Installation Other I I nstallation R R equirements Electrical C C onnection Safety P P recautions Principle o o f I I nduction Glass T T op, C C oil S S ize a a nd C C ontrols Controls a a nd O O peration Heating Z Z ones, C C oil S S izes &... -
Page 6: Before Installation
After delivery, have your induction cooktop carefully unpacked, and again check forany visible damage. If you find any damage onthe unit at this point, immediately inform your dealer or distributor. -
Page 7: Installation
1 / INSTALLATION To install the cooktop, cut out a rectangular opening in the counter as shown on the drawing and table below. Also, ensure that you have a minimum of 10 mm (3/8”) of space in the back of the unit, between the rim and backsplash on your counter (or wall if no backsplash) for ventilation. - Page 8 The air intake is on the bottom of the cooktop box, and the warm air exhaust is located on the back of the rim, as shown on the schematic. If the air...
- Page 9 Electrical Connection cooktop e e lectrical c c haracteristics a a re: Operating voltage... 240 V~ 60 Hz Maximum power output ... 9600 W 40A Connect to ... 240 V, 60 Hz, 50 A minimum supply, Electrical w w iring i i nformation An adequate electrical supply must be provi- ded for this unit.
- Page 10 If the unit is connected directly to supply inside a junction box, then disconnect its breaker, or remove fuses manually. Do not re-use your cooktop until the glass top is changed. When cooking never use aluminum foil and never place products wrapped in aluminum foil, nor products deep-frozen in aluminum packs on the hob.
- Page 11 The p p rinciple o o f i i nduction When an induction element - also called: ‘a heating zone’, or simply: ‘a coil’ - is switched on, the appropriate utensil is used, and a desi- red level of heating power selected, the elec- tronic circuit unit (‘induction generator’...
-
Page 12: Description Of The Control Panel
Glass Top, Coil Size and Controls 16 c c m(6” 50 W à 2200 W cm ( ( 9”) 50 W à 2800 W DESCRIPTION OF THE CONTROL • PANEL Start/stop touch control. Power - + touch controls. Power pre-select touch controls. cm (9”) 50 W à... -
Page 13: Which Cooking Zone Should You Use Based On Your Cookware
• WHICH COOKING ZONE SHOULD YOU USE BASED ON YOUR COOKWARE? Cooking Diameter A zone 16 c c m ( ( 6 ”) 10 ..1 1 8 c c m ( ( 4..7”) 22 c c m (9 ” ” ) 18 . - Page 14 If a utensil is left on an element at full power, temperature of the dish may increase rapidly, the safeties would not engage, and this may damage your utensil, the cooktop, and could result in an injury or a damage to your property. induction cooking, but most manufacturers...
- Page 15 Your cooktop must never be used as a storage space or surface for piling up of any material. - Avoid storing flammable products in the cabinets under your cooktop.
-
Page 16: Daily Care Of Your Appliance
3 / DAILY CARE OF YOUR APPLIANCE MAINTAINING YOUR APPLIANCE • Cleaning of an induction cooktop is easy. Read and follow these TYPE O O F S S TAINS/SPOTS Minor Accumulated burn-on stains. Rings and traces of lime scale. Burn-on stains following sugar spillage, melted aluminium or plastic. -
Page 17: Special Messages, Difficulties
4 / SPECIAL MESSAGES, DIFFICULTIES You have doubts about whether your hob is working correctly. This does not necessarily mean that there is a breakdown. Nevertheless, check the following points. P R O B L E M When you switch the unit on, the supply-line breaker trips off or the supply-line fuse burn. - Page 18 FAGOR AMERICA, INC. PO BOX 94 LYNDHURST, NJ 07071 Toll Free: 1.800.207.0806 Email: infoappliances@fagoramerica.com www.fagoramerica.com The manufacturer reserves the right to modify the items described in this manual.
