Faber 6058028 Specifications

Scirocco
a disappearing downdraft
downdraft vent system
°
pops up and down
°
flush with cooktop in down position
°
sleek design
°
safety microswitches
°
500 cfm for internal blower
°
900 cfm for remote blower
°
variable speed control
°
dishwasher safe grease filters
°
stainless steel trim
°
four way venting
°
sone range: 3.5 - 6.5
°
3 1/4" x 10" duct (internal)
°
10" round duct (remote)
°
Size/Color/Model #
30 SS Internal
36 SS Internal
30 SS Remote
36 SS Remote
900 cfm Rmt Blwr
NOT FOR USE WITH COMMERCIAL COOKTOPS
p.o. box 435 • Wayland, MA 01778 • tel: (508) 358-5353 • fax: (508) 358-5730 • e-mail: info@faberonline.com • www.faberonline.com
SCIR3008IB
SCIR3608IB
SCIR3008RB
SCIR3608RB
RBORIG900
Integrated Collection
The Scirocco downdraft is perfect for island installations,
where an overhead canopy would be obstructive, or wall
installations where cabinet space is at a premium.
Rising a full 8 1/4" above the cooktop, the Scirocco vents horizontally
across the cooking surface and down through the exhaust vent. At
the press of a button, the stainless steel Scirocco retracts back down
into the counter.
Momentary delay up/down
button prevents the unit
from raising or lowering
when cleaning the top trim.
Spring secured top trim
pops off automatically if an
object or finger obstructs
its path.
Safety microswitches on
the grease filters prevent
the Scirocco from lowering
when grease filters are not
installed.
For more power, the
Remote Blower can be
mounted on the wall or roof
outside the home
R E A D T H E I N S TA L L AT I O N
INSTRUCTIONS FOR BOTH
THE REMOTE BLOWER AND
THE SCIROCCO DOWNDRAFT
SYSTEM BEFORE INSTALLING
EITHER PRODUCT.
