Main Bios Setup Screen - Intel VS440FX Technical Specification

Table 15. Overview of the Setup Menu Screens (continued)
Setup Subscreen
Floppy Options
IDE Device Configuration
Boot Options
Peripheral Configuration
Advanced Chipset
Configuration
Power Management
Configuration
Plug and Play
Configuration
Event Logging
Configuration

3.15.2 Main BIOS Setup Screen

This section describes the Setup options found on the main menu screen. If you select certain
options from the main screen (e.g., Hard Disk), Setup switches to a subscreen for the selected
option.
3.15.2.1 System Date
Specifies the current date. Select the month from a pop-up menu.
3.15.2.2 System Time
Specifies the current time.
3.15.2.3 Floppy Options
When selected, this displays the Floppy Options menu.
3.15.2.4 Primary IDE Master
Reports if an IDE device is connected to the Primary IDE master interface. When selected, this
displays the IDE Device Configuration subscreen.
3.15.2.5 Primary IDE Slave
Reports if an IDE device is connected to the Primary IDE slave interface. When selected, this
displays the IDE Device Configuration subscreen.
3.15.2.6 Secondary IDE Master
Reports if an IDE device is connected to the Secondary IDE master interface. When selected, this
displays the IDE Device Configuration subscreen.
Description
Configure diskette drives.
Configure IDE devices such as hard disk drives.
Modify options that affect the system boot up, such as the boot sequence.
Modify options that affect the serial ports, the parallel port, and the disk drive
interfaces.
Modify options that affect memory and system buses.
Access and modify APM options.
Modify options that affect the system's Plug and Play capabilities.
Access and modify event logging options.
BIOS and Setup Utility
49
