Oki C7200 Handy Reference page 26

C
hanging Toner Cartridges (cont.)
7. Hold the cartridge in a vertical
position with port on the left and
the blue lock lever on the right,
then lower the left end into the
image drum, sliding the tube on the
drum into the port on the toner
cartridge.
8. Press the cartridge toward the left
slightly, then lower the right end,
aligning the white tab (1) with the
groove in the drum.
9. Push the blue lock lever toward the
back of the printer as far as it will
go.
Caution! Be sure to push the lock
lever all the way back. If it is not
pushed back and you close the cover,
the lever could damage the LED
printhead.
10. Use the LED lens cleaner
supplied with the toner to wipe
clean the LED head.
11. Close the cover.
12. Turn the printer back on.
Important! After the new toner
cartridge is installed, the TONER
LOW message should disappear
from the display. If it doesn't, try
printing a page. If it still doesn't
disappear, reinstall the toner
cartridge
26
