Single-Phase AC Cabling for USA

Caution

Connecting the Power Supply Cord

40
The HP SureStore E Disk Array XP48 has two main disconnect devices
(two main Breaker CB101 for dual power lines) so that AC power of the
unit can be supplied from the separate power distribution board with two
power supply cords.
before connecting the equipment to the power source.
The unit has two power supply cords with attachment plug type R&S
3720DP. Be sure to prepare the following socket receptacles between the
power distribution board of the building and the attachment plugs for the
unit:
• Socket receptacle: R&S 3743 or 3913 or equivalent
• The power cord that is provided with your disk array is type SJT or
equivalent, nonshielded type, with three min. #10 AWG conductors,
terminated at one end with an assembled on above socket receptacle
cap.
Observe all instructions described in this manual
HP SureStore E Disk Array 48: Site Prep Guide
