Single-Phase Cabling for Europe
Caution
Connecting the Power Supply Cord
87Ã
87Ã
42
The HP SureStore E Disk Array XP48 has two main disconnect devices
(two main Breaker CB101 for dual power lines) so that AC power of the
unit can be supplied from the separate power distribution board with two
power supply cords.
before connecting the equipment to the power source.
The unit has two power supply cords. The power cord included with the
unit is a type H07RN-F or equivalent, with five 2.5 mm
Be sure to connect a power cord to the distribution box as illustrated in the
figure below. To reduce the risk of a wrong connection, use a socket
approved for this disk array.
Observe all instructions described in this manual
/
/
*
HP SureStore E Disk Array 48: Site Prep Guide
2
conductors.
