INSTALLATION
MANUAL
*Blower may be rotated for horizontal or vertical direction by loosening nuts around blower inlet. Accessible inside ventilation
chamber.
TIE DOWN BOLT
ON EACH END
BLOWER
GREASE CONTAINER
²
9
3/8
23.81 cm
² Min.
1
7/8
4.76 cm
(Min.)
Top Front
Edge to
Cutout
MODEL SERIES: JED8345 TRIPLE BAY
Minimum Clearance
Required
S
Dimension "B" - Provide 2² min. (5.08 cm) cabinet clearance to motor for cooling purpose.
S
Installer - Where possible, 6² (15.24 cm) is recommended for motor/blower service.
S
Side Clearance - Grill models installed near a side wall must allow a minimum clearance of 6² (15.24 cm) for
maximum performance.
S
Electrical Hook UP - The unit should be properly circuit protected and wired according to local electrical codes. See
electrical wiring information on back. Unit power requirements are located on the data plate.
S
** Access must be provided to remove and empty grease container(s).
Electric Convertible Cooktop
Models JED8130, JED8230 & JED8345
DIMENSIONS SHOWN IN BOTH INCHES AND CENTIMETERS
GREASE
CONTAINER
WIRING BOX COVER
21+1/16²
53.34 cm
²
7
9/16
19.21 cm
MODELS
JED8130, JED8230
JED8345
Typ. for Container Supplied.
6 1/4² (15.88 cm) is required for removal.
ONLY MODELS WITH GRILLING FEATURE HAVE BEEN ILLUSTRATED
INSTRUCTIONS TO INSTALLER
403 WEST FOURTH STREET, NORTH · NEWTON, IA 50208
S
NOTICE TO INSTALLER: Leave these instructions
with the appliance.
S
NOTICE TO CONSUMER: Retain these instructions
for future reference.
9
3/8
23.81 cm
13²
33.02 cm
A
Double Bay
Triple Bay
MODEL SERIES: JED8130 & JED8230 DOUBLE BAY
²
INCHES
29 + 1/16
43 1/4 + 1/16 109.86 + .16
8101P421-60
CM
73.66
(10-01-00)
