Tecra
M5 Series
Resource Guide
Keep this guide in a convenient place to access important
information about your computer.
If you need assistance:
❖ Toshiba's Support Web site
pcsupport.toshiba.com
❖ Toshiba Global Support Centre
Calling within the United States (800) 457-7777
Calling from outside the United States (949) 859-4273
Please fill in for your reference and future use:
Model name______________________________________
Part number______________________________________
Serial number____________________________________

Advertisement

Table of Contents
loading

Related Manuals for Toshiba Tecra M5-S5131

Summary of Contents for Toshiba Tecra M5-S5131

  • Page 1 Resource Guide Keep this guide in a convenient place to access important information about your computer. If you need assistance: ❖ Toshiba’s Support Web site pcsupport.toshiba.com ❖ Toshiba Global Support Centre Calling within the United States (800) 457-7777 Calling from outside the United States (949) 859-4273...

  • Page 2: Table Of Contents

    Your computer’s TFT display ............. 30 Inserting a PC Card................30 Removing a PC Card................. 31 Learning the basics................31 Using the Toshiba Dual Pointing Device..........32 Using the TouchPad™ ............... 32 Using the optical drive ..............33 Moving the computer................ 36 Mobile computing................
  • Page 3 ALTERED OR LOST DUE TO ANY TROUBLE, FAILURE OR MALFUNCTION OF THE HARD DISK DRIVE OR OTHER STORAGE DEVICES AND THE DATA CANNOT BE RECOVERED, TOSHIBA SHALL NOT BE LIABLE FOR ANY DAMAGE OR LOSS OF DATA, OR ANY OTHER DAMAGE RESULTING THEREFROM. WHEN COPYING OR TRANSFERRING YOUR DATA, PLEASE BE SURE TO CONFIRM WHETHER THE DATA HAS BEEN SUCCESSFULLY COPIED OR TRANSFERRED.
  • Page 4 ANY CRITICAL APPLICATIONS. IF YOU USE THE COMPUTER PRODUCTS IN A CRITICAL APPLICATION, YOU, AND NOT TOSHIBA, ASSUME FULL RESPONSIBILITY FOR SUCH USE. EU Declaration of Conformity TOSHIBA declares that this product conforms to the following Standards: Supplementary *The product complies with the Information:...
  • Page 5 2. If this equipment causes RF interference to other radio stations, promptly change the frequency being used, change the location of use, or turn off the source of emissions. 3. Contact TOSHIBA Direct PC if you have problems with interference caused by this product to Other Radio Stations. 2. Indication The indication shown below appears on this equipment.

  • Page 6: Device Authorization

    This equipment uses a frequency bandwidth from 2,400 MHz to 2,483.5 MHz. It is possible to avoid the band of mobile object identification systems. 3. TOSHIBA Direct PC Monday – Friday: 10:00 – 17:00 Toll Free Tel: 0120-15-1048 Direct Dial: 03-3457-4850...
  • Page 7 This device works on passive scan only. A peer-to-peer mode is not available in 802.11a and Turbo Mode. 802.11b (2.4 GHz) Australia Austria Belgium Canada Denmark Finland France Germany Greece Ireland Italy Liechtenstein Luxembourg Netherlands New Zealand Norway Portugal Sweden Switzerland Europe - Restrictions for use of 2.4 GHz Frequencies in European Community Countries...
  • Page 8 Nederland: License required for outdoor installations. Check with reseller for procedure to follow. Licentie verplicht voor gebruik met buitenantennes. Neem contact op met verkoper voor juiste procedure. 802.11a (5 GHz) Australia Austria Belgium Canada Denmark Finland France Germany Greece Ireland Italy Liechtenstein Luxembourg...
  • Page 9 ❖ This device must not be operated in ad-hoc mode using channels in the 5 GHz bands in the European Community. Ad-hoc mode provides a direct communication between two client devices without a Wireless LAN Access Point. ❖ This device must be used with Access Points that have employed and activated a radar detection feature required for European Community operation in the 5 GHz bands.

  • Page 10: Wireless Lan Card

    Sweden Switzerland Uruguay Venezuela Approved Countries/Regions for use for the Toshiba Mini PCI Wireless LAN Card This equipment is approved to the radio standard by the countries/regions in the following table. Do not use this equipment except in the countries/regions in the following table.

  • Page 11: Bluetooth Wireless Technology Interoperability

    Bluetooth Wireless Technology Interoperability ® Bluetooth Cards from TOSHIBA are designed to be interoperable with any product with Bluetooth wireless technology that is based on Frequency Hopping Spread Spectrum (FHSS) radio technology, and is compliant to: ❖ Bluetooth Specification as defined and approved by The Bluetooth Special Interest Group.
  • Page 12 Always use Bluetooth cards from TOSHIBA in order to enable wireless networks over two or more (up to a total of seven) TOSHIBA portable computers using these cards. Please contact TOSHIBA computer product support on Web site http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or pcsupport.toshiba.com in the United States for more information.

  • Page 13: Bluetooth Wireless Technology And Your Health

    The radiated output power of the Bluetooth Card from TOSHIBA is far below the FCC radio frequency exposure limits. Nevertheless, the Bluetooth Card from TOSHIBA shall be used in such a manner that the potential for human contact during normal operation is minimized.

  • Page 14: Regulatory Statements

    Regulatory statements This product complies with any mandatory product specification in any country/region where the product is sold. In addition, the product complies with the following: European Union (EU) and EFTA This equipment complies with the R&TTE directive 1999/5/EC and has been provided with the CE mark accordingly.
  • Page 15 2. If this equipment causes RF interference to other radio stations, promptly change the frequency being used, change the location of use, or turn off the source of emissions. 3. Contact TOSHIBA Direct PC if you have problems with interference caused by this product to Other Radio Stations. 2. Indication The indication shown below appears on this equipment.
  • Page 16 CD-RW drive, Multi-drive or any other optical drive. You could damage the drive. You would also be exposed to laser light or other safety hazards, resulting in serious injury. Always contact an authorized Toshiba service provider, if any repair or adjustment is required.
  • Page 17 This guide is copyrighted by Toshiba America Information Systems, Inc. with all rights reserved. Under the copyright laws, this guide cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed, however, with respect to the use of the information contained herein.
  • Page 18 Sony Corporation. Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. Other trademarks and trade names are those of their respective owners.

  • Page 19: Introduction

    (RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements and verifies its suppliers’ commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.

  • Page 20: Setting Up Your Computer And Getting Started

    For accessory information, visit Toshiba’s Web site at accessories.toshiba.com. Setting up your computer and getting started The Toshiba Instruction Manual for Safety and Comfort, that shipped with your computer, contains helpful information for setting up your work environment and tips for working comfortably throughout the day.
  • Page 21 Setting up your computer and getting started Never allow any liquids to spill into any part of your computer, and never expose the computer to rain, water, seawater or moisture. Exposure to liquid or moisture can cause electric shock or fire, resulting in damage or serious injury.
  • Page 22 TOSHIBA Battery Charger (that may have been provided with your computer), or use AC adaptors and battery chargers specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor or Battery Charger could cause fire or damage to the computer, possibly resulting in serious injury.
  • Page 23 Setting up your computer and getting started To connect AC power to the computer: Connect the power cord/cable to the AC adaptor. (Sample Illustration) Connecting the power cord/cable to the AC adaptor Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

  • Page 24: Adding Memory (Optional)

    Adding memory (optional) HINT: To purchase additional memory modules, see the accessories information packaged with your system or visit accessories.toshiba.com. Your computer comes with enough memory to run most of today’s popular applications. You may want to increase the computer’s memory if you use complex software or process large amounts of data.
  • Page 25 Adding memory (optional) Installing a memory module Memory modules can be installed in the memory module slots on the base of the computer. You will need a small Phillips screwdriver for this procedure. If the computer has been running recently, the memory module may be hot.
  • Page 26 Adding memory (optional) Remove the main battery. For information on removing the main battery, see “Removing the battery from the computer” on page 39. Close the display panel and turn the computer upside down to locate the memory module slot cover. Memory module slot cover Front of computer...
  • Page 27 Adding memory (optional) Carefully remove the new memory module from its antistatic packaging, without touching its connector. 10 Locate an empty memory module slot on the underside of the computer. If no memory slot is available, you must remove a module by performing steps 2-3 of “Removing a memory module”...
  • Page 28 Adding memory (optional) 13 Once the module’s connector is fully inserted into the socket, press downward on the top edge of the module to seat the module into the latches at the sides of the socket. These latches should “snap” into place securely with the corresponding cutouts in the side of the module.

  • Page 29: Removing A Memory Module

    Adding memory (optional) TECHNICAL NOTE: You must have at least one memory module installed for the computer to work. Removing a memory module If you need to remove a memory module: Complete steps 1–8 in “Installing a memory module” on page 25 to shut down the computer and open the memory module slot cover.

  • Page 30: Your Computer's Tft Display

    Your computer’s TFT display Replace the memory module slot cover and secure it using the screw. Re-insert the main battery. For more information on inserting the main battery, see “Inserting a charged battery” on page 40. Turn the computer right side up. Reconnect the cables.

  • Page 31: Removing A Pc Card

    Removing a PC Card Removing a PC Card Be sure to disable the PC Card prior to removing it. Otherwise, the system may be damaged. Before removing a PC Card, make sure that no applications or system services are using the card. Prepare the card for removal by clicking the Safely Remove Hardware icon in the Notification Area and then selecting the PC Card device.

  • Page 32: Using The Toshiba Dual Pointing Device

    Accupoint II secondary button TouchPad™ TouchPad secondary button TouchPad primary button (Sample Illustration) Toshiba Dual Pointing Device buttons ® Accupoint II pointing device—Moves the cursor and selects items on the screen. To move the cursor, gently push the pointing device in the direction you want the cursor to move.

  • Page 33: Using The Optical Drive

    Using the optical drive Once you have positioned your cursor, you can click it into place by either double-tapping the TouchPad or clicking the control buttons. ™ Scrolling with the TouchPad ™ There are two active regions on the TouchPad that allow you to scroll as you would with any wheel device on a mouse or trackball.
  • Page 34 Using the optical drive Your optical drive may look like this: Drive in-use indicator light Eject button Manual eject hole (Sample Illustration) Optical drive Drive in-use indicator light—Indicates when the drive is in use. Eject button—Press to release the disc tray. Do not press the eject button or turn off the computer while the drive in-use indicator light is glowing.
  • Page 35 If you insert the disc incorrectly, it may jam the drive. If this happens, contact Toshiba support for assistance. Push the disc tray in by pressing gently on the center of the tray until it clicks into place.

  • Page 36: Moving The Computer

    ❖ EasyGuard Optimize—to enable users to customize system settings to be more productive. ™ *Toshiba EasyGuard technology comprises a number of features some of which may or may not be available on a particular Toshiba notebook depending on the model selected. See easyguard.toshiba.com for detailed information.
  • Page 37 This is normal for all batteries. To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba Web site at accessories.toshiba.com. Use only batteries designed to work with your Toshiba notebook computer.
  • Page 38 Mobile computing ❖ Is unlit when the battery has discharged, the battery is not charging, or the AC adaptor is not plugged into the computer or AC outlet Battery life and charge time may vary, depending upon power management settings, applications and features used. ❖...
  • Page 39 Mobile computing Removing the battery from the computer To remove the battery: Save your work. Turn off the computer or place it in Hibernation mode according to the instructions in “Using and configuring Hibernation mode” in the electronic user’s guide. Unplug and remove any cables connected to the computer, including the AC adaptor.

  • Page 40: Taking Care Of Your Battery

    Taking care of your battery If the battery is leaking or its case is cracked, put on protective gloves to handle it, and discard it immediately. Always dispose of used battery packs in compliance with all applicable laws and regulations. Put insulating tape, such as cellophane tape, on the electrode during transportation to avoid a possible short circuit, fire or electric shock.
  • Page 41 ❖ If a battery is leaking or damaged, replace it immediately. Use protective gloves when handling a damaged battery. ❖ To replace the main battery, use an identical battery that you can purchase through the Toshiba Web site at accessories.toshiba.com. ❖ A reverse polarity condition should be avoided with all batteries.
  • Page 42 If you cannot find the information you need elsewhere, call Toshiba at: (800) 457-7777. Toshiba is dedicated to preserving the environment by sponsoring Call2Recycle, a program of the Rechargeable Battery Recycling Corporation.

  • Page 43: If Something Goes Wrong

    If something goes wrong If something goes wrong Problems that are easy to fix Your program stops responding. If you are working with a program that suddenly freezes all operations, chances are the program has stopped responding. You can exit the failed program without shutting down the operating system or closing other programs.
  • Page 44 If something goes wrong Problems when you turn on the computer These problems may occur when you turn on the power. The computer will not start. Make sure you attached the AC adaptor and power cord/cable properly or installed a charged battery. Press and hold the power button for at least 10 seconds.
  • Page 45 If something goes wrong You may have activated the instant password feature by pressing simultaneously. If you have registered a password, press any key, type the password and press Enter . If no password is registered, press any key. The screen reactivates and allows you to continue working.

  • Page 46: If You Need Further Assistance

    Since some problems may be related to the operating system or the program you are using, it is important to investigate other sources of assistance first. Try the following before you contact Toshiba: ❖ Review the troubleshooting information in your operating system documentation.

  • Page 47: Power Cord/Cable Connectors

    Power cord/cable connectors For the number of a Toshiba dealer near you, see “Toshiba voice contact” in this section. Contacting Toshiba If you still need help and suspect that the problem is hardware- related, Toshiba offers a variety of resources to help you.

  • Page 48: Index

    Index AC adaptor eject button AC power light optical drive backing up files files backing up battery saving changing installing 40, 42 inserting notification CD/DVD real-time clock (RTC) PC Cards removing installing buttons main battery 40, 42 eject, optical drive memory module TouchPad control keyboard...
  • Page 49 TouchPad Features and specifications printer connecting tips on computing problem solving Toshiba Accessories computer hangs when PC Card information inserted TouchPad computer will not start using 32, 33 contacting Toshiba display is blank external monitor...
  • Page 52 GMA500385010 01/07...
