Tecra M5 Series Detailed Product Specification
Model Name
Description
M5-ST8112
Microsoft® Windows® XP Professional, Intel® Core™ Solo Processor T1300, 512MB
DDR2, 40GB 5400rpm (S-ATA), CD-RW/DVD-ROM, 14.1" XGA, nVIDIA® Quadro NVS
110M w/ 128MB, Intel® PRO/Wireless 3945ABG (802.11a/b/g), 1-year standard limited
warranty.
2
Operating System
• Microsoft® Windows® XP Professional
3
Processor and Chipset
Intel® Centrino® Mobile Technology featuring:
• Intel® Core™ Solo Processor T1300
o 1.66GHz, 2MB L2, 667MHz FSB
• Chipset
o Mobile Intel® 945GM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
Intel® Centrino® Duo Mobile Technology featuring:
• Intel® Core™ Duo Processor T2300
o 1.66GHz, 2MB L2, 667MHz FSB
• Intel® Core™ Duo Processor T2400
o 1.83GHz, 2MB L2, 667MHz FSB
• Intel® Core™ Duo Processor T2500
o 2.00GHz, 2MB L2, 667MHz FSB
• Intel® Core™ Duo Processor T2600
o 2.16GHz, 2MB L2, 667MHz FSB
• Chipset
o Mobile Intel® 945GM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
4
Choice of Memory
• Configured with 512MB DDR2 533MHz SDRAM (using one
memory module, one memory expansion slot open)
• 512MB(min)/4096MB (max), 2 memory slots using 256MB, 512MB,
1024MB, 2048MB PC4200 DDR2 533MHz SDRAM or PC5300
DDR2 667MHz SDRAM, dual-channel support requires two
memory modules of same capacity and clockspeed
Choice of Hard Disk Drive
• 40GB, 60GB, 80GB,100GB, 120GB (5400 RPM) or 100GB
(7200RPM) Serial-ATA (S-ATA) hard disk drive; 9.5mm height
Choice Slim SelectBay Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read)
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read), DVD-R (Single Layer, 8x:write), DVD-R
(Double Layer, 2x: write), DVD-RW (4x:write), DVD+R
(Single Layer, 8x:write), DVD+R (Double Layer,
2.4x:write), DVD+RW (4x:write), DVD-RAM (5x:write)
7
Display
• 14.1" diagonal TFT active-matrix LCD display at 1024x768 native
resolution (XGA)
• 14.1" diagonal TFT active-matrix LCD display at 1400x1050 native
resolution (SXGA+)
5
6
© Copyright 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra M5-ST8112 BT0 Rev. 1.00 2006-01-24 SK T20060113 CB1.05
1
8
Graphics
• nVIDIA® Quadro NVS 110M with 128MB DDR discrete graphics
memory, plus up to 128MB dynamically allocated shared graphics
memory using NVIDIA® TurboCache technology.
Sound
• Built-in stereo speakers
• SigmaTel STAC9200 24-bit stereo software sound
o Supports Direct 3D Sound, DirectSound, Direct Music,
o Connected BUS: High Definition Audio (Intel HD Audio
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• Toshiba Accupoint® and TouchPad™ dual pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control
o Presentation button to quickly connect to projectors
Communications
• Toshiba V.92 software modem
• Intel® 10 Base-T/100 Base-TX/1000 Base-T Ethernet
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR) with
Toshiba Bluetooth driver software (Optional)
• Integrated Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
Expandability
• 2 main memory slots.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
• ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
• Secure Digital slot (supports SDIO)
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o Universal Serial Bus (USB v2.0) – 3 ports
o RJ-45 LAN port
o RJ-11 modem port
o Serial port
o 240-pin docking connector
Part Number
PTM51U-03R01G
MIDI (playback)
1.0 Compatible)
panel
10
11
UPC
032017531833
9
