Toshiba Tecra M5-ST5011 Specifications

Tecra M5-ST5011 Detailed Product Specification
Model Name Description
M5-ST5011 Genuine Windows® XP Professional, Intel® Core™ 2 Duo Processor T5500, 512MB
DDR2, 60GB 5400rpm (S-ATA), CD-RW/DVD-ROM, 14.1" XGA, NVIDIA Quadro NVS
110M w/128MB, Intel® PRO/Wireless 3945ABG (802.11a/b/g), Fingerprint Reader, 1-
year standard limited warranty.
Section 1.01 Operating System
• Genuine Windows® XP Professional
o Windows Vista™ Capable
Section 1.02 Processor and Chipset
Intel® Centrino® Duo Mobile Technology featuring:
• Choice of processors:
o Intel® Core™ 2 Duo Processor T5500
1.66GHz, 2MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T5600
1.83GHz, 2MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T7200
2.00GHz, 4MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T7400
2.16GHz, 4MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T7600
2.33GHz, 4MB L2, 667MHz FSB with
64-bit
• Chipset
o Mobile Intel® 945GM/PM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
5
Section 1.03 Memory
• Configured with 512MB PC5300 DDR2 SDRAM (both memory slots
may be occupied)
• 512MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC4200 or PC5300 DDR2 memory modules.
Section 1.04 Hard Disk Drive
• Choice of: 60GB (5400 RPM), 80GB (5400 RPM), 100GB (5400
RPM), 120GB (5400 RPM) or 100GB (7200 RPM); Serial-ATA
(SATA) hard disk drive; 9.5mm height; user removable
Section 1.05 Slim SelectBay Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x)
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x), DVD-R (Single
Layer, (8x)), DVD-R (Double Layer, (2x)), DVD-RW (4x),
DVD+R (Single Layer, (8x)), DVD+R (Double Layer,
(2.4x)), DVD+RW (4x), DVD-RAM (5x)
8
Section 1.06 Display
• 14.1" diagonal TFT active-matrix LCD display at 1024x768 native
resolution (XGA)
• 14.1" diagonal TFT active-matrix LCD display at 1400x1050 native
resolution (SXGA+)
Section 1.07 Graphics
• PCI-Express™ x16 graphics subsystem, featuring:
2CPU_64
3
4
CPU_64
CPU_64
CPU_64
CPU_64
CPU_64
6
7
9
© Copyright 2005 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra M5-ST5011 BTO Rev. 1.02 2007-02-22 SK T20060830 CB1.60/180
1
o NVIDIA Quadro NVS 110M with TurboCache ™ with
128MB of dedicated graphics memory
Section 1.08
• Built-in stereo speakers
• Sound Volume Control Dial
• Built-in microphone
Section 1.09
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• Toshiba Accupoint® and TouchPad™ dual pointing device
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control
panel
o Presentation button to quickly connect to projectors
Section 1.10
• Toshiba V.92 software modem
• Intel® PRO/1000 VE Network Connection - 10/100/1000 Base-TX
Ethernet
• Integrated Wireless-LAN:
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
• Optional: Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
with Toshiba Bluetooth driver software
Section 1.11
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
• Secure Digital slot (supports SDIO)
Section 1.12
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 3 ports
o RJ-45 LAN port
o RJ-11 modem port
o Serial port
o 240-pin docking connector
o Supported on optional Advanced Port Replicator III/III+:
Part Number UPC
PTM51U-19801G 032017733244
Sound
Input Devices
Communications
10
11
Expandability
Ports
RGB monitor port
DVI-D video port (certain models only)
Audio line-in and line-out
Parallel port
Serial port
PS/2 port
i.LINK™ (certain models only)
