Toshiba Tecra M5-S4333 Specifications

Tecra M5-S4333 Detailed Product Specification
Model Name Description
M5-S4333 Genuine Windows® Vista™ Business, Intel® Core™ 2 Duo Processor T7200 , 2048MB
DDR2, 120GB 5400rpm (SATA), DVD-SuperMulti Drive, 14.1" SXGA+, NVIDIA Quadro
NVS 110M with TurboCache™, Intel® PRO/Wireless 3945ABG (802.11a/b/g), Bluetooth
v2.0 + EDR, 1Gbps LAN, 3-year standard limited warranty
2, C1
Operating System
• Genuine Windows® Vista™ Business
32-bit version
o
Processor and Chipset
Intel® Centrino® Duo Mobile Technology featuring:
• Processor:
o Intel® Core™ 2 Duo Processor T7200
2.00GHz, 4MB L2, 667MHz FSB with 64-bit
• Chipset
o Mobile Intel® 945PM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
5
Memory
• Configured with 2048MB PC5300 DDR2 SDRAM (both memory
slots occupied)
• 512MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC5300 DDR2 memory modules.
6
Hard Disk Drive
• 120GB (5400 RPM); Serial-ATA (SATA) hard disk drive; 9.5mm
height; user removable
Slim SelectBay Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x), DVD-R (Single
Layer, (8x)), DVD-R (Double Layer, (2x)), DVD-RW (4x),
DVD+R (Single Layer, (2x)), DVD+R (Double Layer,
(2.4x)), DVD+RW (4x), DVD-RAM (5x)
8
Display
• 14.1" diagonal TFT active-matrix LCD display at 1400x1050 native
resolution (SXGA+)
9
Graphics
• PCI-Express™ x16 graphics subsystem, featuring:
o NVIDIA Quadro NVS 110M with TurboCache™ with 128MB
of dedicated graphics memory
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• Toshiba Accupoint® and TouchPad™ dual pointing device
• TouchPad™ Enable/Disable
3
4
7
© Copyright 2005 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra M5-S4333 BTS Rev. 1.04 2007-09-05 CM T20061218 CB2.00
a
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control panel
o Windows® Mobility Center Button
Communications
• Toshiba V.92 software modem
• Intel® PRO/1000 Network Connection - 10/100/1000 Base-TX
Ethernet
• Integrated Wireless-LAN:
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
C1
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR) with
Toshiba Bluetooth driver software
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• One ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
• Secure Digital slot (supports SDIO)
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 3 ports
o RJ-45 LAN port
o RJ-11 modem port
o Serial port
o 240-pin docking connector
o Supported on optional Advanced Port Replicator III/III+:
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 12.3" (312.0mm) x 8.51"
(261.0mm) x 1.00" (25.4mm)[F]/1.34" (34.0mm)[R] without feet
• Weight: Starting at 5.23 lbs (2.37 kg) depending upon
configuration
• Chassis Description
o Case material: Magnesium + Polycarbonate ABS
o LCD Cover Color: Titanium Silver
• Physical Security
o Slot for cable lock;
o Items protected by a screw:
o Fingerprint reader
• Software Security
o Passwords: User power-on password, supervisor password
o Hotkey locks: Screen Blank
Part Number UPC
PTM51U-121065 032017816022
10
11
RGB monitor port
DVI-D video port (certain models only)
Audio line-in and line-out
Parallel port
Serial port
PS/2 port
i.LINK™
USB v2.0
12
