Specifications

Camcorder
Recording System: 2 rotary heads, helical scanning system
Recording/Playback Time: 90 minutes (DVM60, LP mode)
Lens Filter Diameter: 30 mm
Built-in microphone: Electret stereo microphone
Colour Temperature Compensation: Auto white balance with white balance lock
Minimum Illumination: 3 lux* (with gain-up, F1.8)
Still Image Compression System: JPEG base line conformance
Still Image Recording Format: JPEG (Exif2.2)
Still Image Recording Medium: SD Memory Card, MultiMediaCard
Power Requirement: DC 7.4 V
Power Consumption: 4.0 W (during camera recording in Tape Camera mode
Operating Temperature: 0°C to L40°C
Operating Humidity: 30% to 80%
Storage Temperature: +20°C to L60°C
Dimensions (WKHKD) (approx.): 82.8 mm K 86.2 mm K 103.5 mm
AC Adapter (UADP-A016WJZZ)
Power Requirement: AC 110–240 V, 50/60 Hz
Dimensions (WKHKD) (approx.): 49.0 mm K 27.5 mm K 79.0 mm
Specifications are subject to change without notice.
*Minimum illumination: Since there is no widely accepted testing procedure for determining
Signal System: PAL standard
Cassette: Digital VCR Mini DV video cassette
Tape Speed: SP mode: 18.831 mm/second
LP mode: 12.568 mm/second
1
Pickup Device: ⁄ " (6.4 mm, effective size: 4.5 mm) CCD image sensor
4
(with approx. 1,330,000 pixels including optical black,
effective pixels: 690,000 pixels in Tape Camera mode,
1,250,000 pixels in Card Camera mode)
Lens: 10K optical zoom lens (F1.8, f=3.8–38.0 mm)
Monitor: 2.5" (6.4 cm) CGSilicon
using the viewfinder in Full Auto mode with the DIS
function on)
4.6 W (during camera recording in Tape Camera mode
using the LCD monitor in Full Auto mode with the DIS
function on and backlight in normal mode)
Weight (approx.): 510 g (without battery pack, lithium battery, video
cassette, lens cap and card)
DC Output: 10 V
Weight (approx.): 125 g
minimum illumination capability, lux ratings are comparable only between
models from the same manufacturer.
107
