Preparation
Installing the Lithium
Batteries
Installing the Memory Battery
The supplied CR 1216 type lithium battery is
used to store the memory of the date and
time settings.
1
Make sure that the Power switch is
set to OFF.
2
Open the LCD monitor to a 90° angle
to the camcorder body.
3
Slide the battery release in the
direction of the arrow, then take the
battery pack out.
Battery release
4
Pull out the lithium battery cover in
the direction of the arrow.
12
5
Insert the smaller lithium battery into
the compartment with the H side of
the battery facing out.
6
Close the lithium battery cover firmly
until it clicks into place.
Removing the Memory
Battery
Perform steps 1 to 4 above,
then lift out the battery by
using a pointed object such
as the tip of a ballpoint pen.
Lithium
battery cover
CR 1216 type
lithium battery
