5
Detailed Zoning Examples
switch1:admin>aliCreate "Private_StorageA", "2,2"
switch1:admin> aliCreate "Private_StorageB", "2,3"
switch1:admin> aliCreate "Private_StorageC",
<Create QuickLoop zones using ports>
switch1:admin> zoneCreate "ql_zone1", "Private_ServerA; Private_StorageA"
switch1:admin> zoneCreate "ql_zone2", "Private_ServerB; Private_StorageB:
switch1:admin> zoneCreate "ql_zone3", "Private_ServerC; Private_Storage
<Create a configuration for QuickLoop zones>
switch1:admin> cfgCreate "cfg1", "qloop1;ql_zone1;ql_zone2;ql_zone3"
<Save and enable the zone configuration>
switch1:admin> cfgSave
Update flash ...
switch1:admin> cfgEnable "cfg1"
Setting switch to Quick Loop mode,
Committing configuration...done.
Initialize Quick Loop...
zone config "cfg1" is in effect
Updating flash ...
switch1:admin>
<This is what the zone configuration should look like>
switch1:admin> cfgShow
Define configuration:
cfg: cfg1 qloop1; ql_zone1;
zone: ql_zone1
zone: ql_zone2
zone: ql_zone3
alias: Private_ServerA
alias: Private_ServerB
alias:Private_ServerC
5-6
ql_zone2; ql_zone3
Private_ServerA; Private_StorageA
Private_ServerB; Private_StorageB
Private_ServerC; Private_StorageC
1,3
1,4
"2,4"
Zoning User's Guide
