5
Detailed Zoning Examples
no configuration defined
Effective confguration:
no configuration in effect
---------------------------------------------------------------------------------
<Create aliases for switch 1 and switch 2 using switches WWNs>
switch1:admin> aliCreate "switch1_WWN", "10:00:00:60:69:10:1c:19"
switch1:admin> aliCreate "swtich2_WWN", "10:00:00:60:69:10:1b:a9"
<Create a dual-switch QuickLoop>
switch1:admin> qLoopCreate "qloop1", "switch1_WWN; switch2_WWN"
Note: The above steps are equivalent to the following:
On switch 1...
<Set QuickLoop partner and enable QuickLoop switch 1>
switch1:admin> qlPartner "10:00:00:60:69:10:1b:a9"
Setting Quick Loop to dual-switch mode,
Committing configuration..done.
switch1:admin> qlEnable
Setting switch to Quick Loop mode,
Committing configuration...done.
Initialize Quick Loop...
switch1:admin>
---------------------------------------------------------------------------
On switch 2...
<Set QuickLoop partner and enable QuickLoop ports on switch 2>
switch2:admin> qlPartner "10:00:00:60:69:10:1c:19"
Setting Quick Loop to dual-switch mode,
COmmitting configuration...done.
switch2:admin> qlEnable
Setting switch to Quick Loop mode,
Committing configuration...done.
Initialize Quick Loop...
switch2:admin>
<Create aliases for QuickLoop devices>
switch1:admin> aliCreate "Private_ServerA", "1,3"
switch1:admin> aliCreate "Private_ServerB", "1,4"
switch1:admin> aliCreate "Private_ServerC", "1,5"
