Motherboard Layout

Figure 1 shows the motherboard and Figure 2 shows the back panel connectors.
12
Figure 1. Board Layout
1. 20-pin ATX Power Connector-PW1
2. System Fan Connector-S_FAN
3. Front Panel Header-FP1
4. Speaker Header-SPK
5. Chip Fan Connector-J2505
6. Serial-ATA (SATA) Connectors
7. BIOS Selection Jumper-JP3(Optional)
8. COM Header-CN2
9. PCI Express x1-PCIE1(Optional)
6
13
2 52
51
Mini PCIE
FP_U2
FP_U1
CN2
PCIE1
11 10 9 8
14 15 16 17
CPU
JP1
Chiset
+
SATA1 SATA4
SATA2 SATA3
JP3
6
7
10. USB Headers-FP_U1~FP_U2
11. Front Audio Header-FP_S1
12. Backpanel Connectors
13. Mini PCIE Slot
14. CPU
15. Chipset
16. Clear CMOS Jumper-JP1
17. CPU Fan Connector-C_FAN
18. DDRII DIMM Sockets
18
121 121
J2505
120 240 120 240
SPK1
5 4
2
3
