Product Specifications - Zotac ZBOX miniHTPC User Manual

Product Specifications

q Chipset
v Intel NM10 Express Family Chipset
®
q Product Size
v 188mm x 188mm x 44mm
q Microprocessor support
v Integrated with Intel
q Operating systems:
v Supports Windows XP 32 bit/64 bit, Windows Vista 32 bit/64 bit and Windows
7 32bit/64bit
q System Memory support
v Two 200-pin SO-DIMMs DDR2-800/667
v Up to 4GB of memory
q USB 2.0 Ports
v Supports hot plug and play
v Six USB 2.0 ports (two front panel ports, four rear panel ports)
v Supports USB 2.0 protocol up to 480 Mbps transmission rate
q Onboard Serial ATA
v Independent DMA operation on one port, data transfer rates of 3 Gb/s
v Support one ESATA port
v Support one 2.5 inch SATA HDD or SSD
q Network support
v Gigabit (10/100/1000Mbps) LAN
v IEEE 802.3 compatible
q WiFi
v 802.11b/g/n compatible
v Enhanced wireless security compatible
q Onboard Audio
v 2-channel High-Definition audio
v Supports Jack-Sensing function
q Green Function
v Supports ACPI (Advanced Configuration and Power Interface)
q Onboard Graphics support
v NIVIDA GeForce GT218 ION GPU, Direct x10.1, Shader Model 4.1,
®
CUDA cores up to 16
v Supports GDDR3 memory up to 512 MB
v Supports Dual_Link DVI & VGA display feature and max resolutions up to
2560x1600 at 60 Hz (DVI) & 2048x1536 at 85 Hz (VGA)
v DVI and HDMI dual output support
Atom processor D5 series
® TM
ZOTAC ZBOX
3
