  • Page 2 ZOTAC. Products and corporate names mentioned in this manual may be registered trademarks or copyrights of their respective companies, and are used for identification purposes only.

  • Page 3: Table Of Contents

    Installing an M.2 SSD 2280 module --------------------------------------------------------------------11 Setting up your ZOTAC ZBOX ------------------------------------------------------------------------------13 Positioning the ZOTAC ZBOX -------------------------------------------------------------------------------15 Mounting the ZOTAC ZBOX to an LCD monitor -----------------------------------------------------15 Installing drivers and software -----------------------------------------------------------------------------17 Installing an operating system ----------------------------------------------------------------------------17 Installing system drivers -----------------------------------------------------------------------------------17...

  • Page 4: Product Specifications

    ZOTAC ZBOX Product specifications Processor • Intel Core i7-14700 Processor (20-core, up to 5.4 GHz) for ZBOX MI673 • Intel Core i5-14400 Processor (10-core, up to 4.7 GHz) for ZBOX MI653 • Intel Core i3-14100 Processor (4-core, up to 4.7 GHz) for ZBOX MI633 Onboard graphics •...

  • Page 5: Safety Information

    ZOTAC ZBOX Safety information Your ZOTAC ZBOX is designed and tested to meet the latest standards of safety for information tech- nology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system Read and follow all instructions in the documentation before operating your system.

  • Page 6: Welcome

    ZOTAC ZBOX Welcome Congratulations on your purchase of the ZOTAC ZBOX. The following illustration displays the package contents of your new ZOTAC ZBOX. If any of the below items are damaged or missing, contact your retailer. Package contents • 1 x ZOTAC ZBOX •...

  • Page 7: Getting To Know Your Zotac Zbox

    ZOTAC ZBOX Getting to know your ZOTAC ZBOX Front view 2 3 4 Refer to the diagram above to identify the components on the front of the ZBOX 1. Power button The power button turns the system ON and OFF.

  • Page 8: Rear View

    ZOTAC ZBOX Rear view Refer to the diagram above to identify the components on the back of the system. 1. WiFi antenna connector The WiFi antenna connector supports the included WiFi antenna. 2. USB 3.2 port The USB 3.2 port supports the SuperSpeed USB 3.2 devices and is backwards compatible with USB 3.1/3.0/2.0/1.1 devices.

  • Page 9: Customizing The Zotac Zbox

    ZOTAC ZBOX Customizing the ZOTAC ZBOX Before installing hardware, please follow the instructions below to remove the cover of your ZOTAC ZBOX. 1. Remove the four thumb screws securing the bottom cover into place. 2. Remove the bottom cover.

  • Page 10: Installing A Memory Module

    2. Gently press down on the memory module until it locks into place by the arms of the memory slot. Note: This ZOTAC ZBOX accomodates two DDR5 SO-DIMM memory modules. You must install at least one module for the system to function. Windows models include memory pre-installed.

  • Page 11: Removing The Memory Module

    ZOTAC ZBOX Removing the memory module 1. Locate the SO-DIMM memory slot and gently press the two arms securing the memory module outwards, as shown in the image below, to release the memory module. 2. Remove the memory module from the slot at a 45-degree angle.

  • Page 12: Installing An M.2 Ssd 2280 Module

    ZOTAC ZBOX Installing an M.2 SSD 2280 module 1. Locate the M.2 SSD 2280 slot and remove the screw from the bolt. 2. Insert the M.2 SSD module into the slot, and install the screw on board.
  • Page 13 ZOTAC ZBOX Note: After installing the SSD and memory module, please remove the correspond- ing protective film from thermal paste.

  • Page 14: Setting Up Your Zotac Zbox

    ZOTAC ZBOX Setting up your ZOTAC ZBOX Please connect your peripherals before using your ZOTAC ZBOX 1. Connecting the WiFi antenna Connect the WiFi antenna to the WiFi antenna connector. 2. Connecting to USB 3.2 devices Connect USB 3.2 devices such as external hard disk drives, SSDs and flash drives to the USB 3.2 port on the system rear panel.
  • Page 15 Connect the supplied AC adapter to the DC IN jack on the system rear panel and then press the power switch on the front panel to turn on the system.  When your ZOTAC ZBOX is not in use, unplug the power adapter or switch off the AC outlet to conserve power.

  • Page 16: Positioning The Zotac Zbox

    Disclaimer: ZOTAC cannot be held liable for damages resulting from an improper installation. Align the ZOTAC ZBOX mounting holes to the VESA mount attachment pegs. Attach the ZOTAC ZBOX to the VESA mount and gently press down to secure the ZBOX to the mount.
  • Page 17 ZOTAC ZBOX Connect the ZOTAC ZBOX to your LCD monitor with an HDMI/DP cable.

  • Page 18: Installing Drivers And Software

    Install system drivers to gain full functionality of the ZOTAC ZBOX hardware and features. Installing system drivers Before you can use the full features of the ZOTAC ZBOX, the system drivers must be installed. The following types of operating systems are supported by the USB flash drive: •...

  • Page 19: Using Your Zotac Zbox

    ZOTAC ZBOX • Intel Management Engine Each driver must be installed individually to ensure proper operation of the ZOTAC ZBOX.  Select the driver you want to install. The driver installer should launch. Follow the onscreen instructions to install the drivers.

  • Page 20: Configuring Audio Output

    ZOTAC ZBOX Configuring audio output Follow the steps below to enable audio output when connecting the ZOTAC ZBOX to a TV or receiver via DP/HDMI adapter. Access the Sound settings via the system Control Panel. Under Playback devices, click the display device that corresponds with your audio compatible display.

  • Page 21: Fcc Warning

    ZOTAC ZBOX FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 22: Ic Warning

    ZOTAC ZBOX IC Warning This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; (2) This device must accept any interference, including interference that may cause undesired operation of the device.
