Jenn-Air JS48SEDUDB01 Parts List page 16

REFRIGERATOR DOOR PARTS
For Model: JS48SEDUDB01
Illus. Part
No. No.
1 W10197114 Refrigerator
3 2266854 Hinge Assembly,
4 2316804 Spacer−Door,
5 489282 Screw
6 2302878 Hinge Assembly,
7 2222797 Rail, Lid
8 2222983 Gaasket, Utility
9 2222812 Door Gasket,
10
W10144970 Stainless Steel
11
12850908 Stainless Steel
12
2309060 For Stainless
13 W10153450 Stud, Handle
14 488568 Screw
15
8281250 Stainless Steel
16 2005433 Spacer, Door−Skin
17 308544 Screw, Handle
18 2309056 Spacer, Door−Skin
19 2004935 Spacer, Door−Skin
20 2005327 Filler, Door
21
2222919 Right Side
2222920 Left Side
22 W10127710 Plate, Door−Handle
25 2222923 Bin, Utility
26 2257617 Door, Utility Bin
27 2222774 Bin, Door (3)
30 2222771 Bin, Door
(Stainless Steel)
DESCRIPTION
Door Panel
(Includes
Item #9)
Top
Top & Bottom
Bottom
Bin
Magnetic
Skin, Door
Handle, Door
Spacer, Door−Skin
(Handle Side)
Steel Model
Screw, 8−15 x .500
(Top)
(Hinge Side)
(Bottom)
End Cap
Center
16 W10242820
