Wells B446 Operation Manual
Built-in electric char broilers
Hide thumbs
Also See for B446:
- Supplemental service instructions (28 pages) ,
- Operation manual (24 pages) ,
- Operation manual (16 pages)
Table of Contents
Advertisement
Quick Links
Model B-406
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
303673
p/n 2M-
Rev. F
WELLS BLOOMFIELD, LLC
10 Sunnen Dr., St. Louis, MO 63143
telephone: 314-678-6314
Model B-446
IMPORTANT: DO NOT DISCARD THIS MANUAL
fax: 314-781-2714
www.wells-mfg.com
OPERATION
MANUAL
BUILT-IN
ELECTRIC
CHAR
BROILERS
includes:
INSTALLATION,
USE and CARE
for
Models:
B406
B446
B506
13
M162
0214
162
Advertisement
Table of Contents
Related Manuals for Wells B446
Summary of Contents for Wells B446
-
Page 1: Use And Care
Additional manuals are available from your WELLS DEALER. THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any questions concerning installation, operation or maintenance of this equipment. -
Page 2: Warranty
(314) 678-6314 or fax (314) 781-2714 if service is performed by unauthorized personnel. The prices charged by Wells Bloomfield for its products are for information and other details concerning warranty. SERVICE POLICY AND PROCEDURE GUIDE and ADDITIONAL WARRANTY EXCLUSIONS Resetting of safety thermostats, circuit breakers, over cleaning schedules, are customer responsibility. -
Page 3: Table Of Contents
TABLE OF CONTENTS WARRANTY Thank you for purchasing this SPECIFICATIONS Wells Bloomfield appliance. FEATURES & OPERATING CONTROLS PRECAUTIONS & GENERAL INFORMATION Proper installation, professional AGENCY LISTING INFORMATION operation and consistent INSTALLATION maintenance of this appliance OPERATION will ensure that it gives you the... -
Page 4: Features & Operating Controls
FEATURES & OPERATING CONTROLS ITEM COMMENT TEMPERATURE CONTROL The char-broiler is INFINITE SWITCH CONTROLLED. Power is applied to the heating elements based on the control knob position and the amount of energy used. INDICATOR LIGHT Light will glow when the infinite switch is in any position other that OFF. The char-broiler element assembly may be raised for cleaning, or to HEATING ELEMENT ASSEMBLY... - Page 5 FEATURES & OPERATING CONTROLS (continued) Fig. 1 Built-In Electric Charbroiler Fig. 2 Wellsloks...
-
Page 6: Precautions & General Information
PRECAUTIONS AND GENERAL INFORMATION Broilers are intended for use to cook food products for human WARNING: Electric Shock consumption. No other use is recommended or authorized by the Hazard manufacturer or its agents. All servicing requiring access to non-insulated electrical Broilers are intended for use in commercial establishments, where all components must be users are familiar with the appliance limitations, use and associated... -
Page 7: Installation
INSTALLATION UNPACKING & INSPECTION NOTE: DO NOT discard the carton or other packing Carefully remove the appliance from the carton. Remove all protective materials until you have plastic film, packing materials and accessories from the appliance inspected the appliance for before connecting electrical power or otherwise performing any hidden damage and tested it installation procedure. - Page 8 INSTALLATION (continued) ELECTRCAL HOOK-UP WARNING: Risk of personal Refer to the nameplate. Verify the electrical service power. Voltage injury and phase must match the nameplate specifications. Connecting the Installation procedures must griddle to the wrong voltage can severely damage the unit or cause be performed by a qualified noticeable decreased performance.
-
Page 9: Operation
OPERATION PREPARE THE CHAR-BROILER FOR USE CAUTION: Hot Surface When using the broiler for the first time, wipe the entire unit with a clean Exposed surfaces can be hot damp cloth or sponge and mild to the touch and may cause detergent. - Page 10 OPERATION (continued) CAUTION: TEMPERATURE CONTROLS Hot Surface Each section of the broiler is equipped with an individual temperature Exposed surfaces control. The desired temperature is controlled by rotating the can be hot to the touch and TEMPERATURE CONTROL KNOB. Any time the control is turned may cause burns.
-
Page 11: Broiler Chart
OPERATION (continued) BROILER CHART RECOMMENDED COOKING TIMES AND DIAL SETTINGS NOTE: The times and dial settings in this chart are suggestions only. Your own experience with your own menu items will be your best guide to achieving the best food product. -
Page 12: Troubleshooting Suggestions
240V unit run on 208V Verify proper voltage Damaged component or wiring Contact an Authorize Wells Service Agency for repairs Temperature control not set Set temperature control knob to One or more section too desired temperature... -
Page 13: Cleaning Instructions
CLEANING INSTRUCTIONS PREPARATION CAUTION: Electric Shock Turn both temperature control knobs OFF. Allow broiler to cool completely. Hazard Disconnect broiler from electric power. Disconnect appliance from electric power before FREQUENCY Daily. cleaning. TOOLS CAUTION: Burn Hazard Steel Brush with Scraper Plastic Scouring pad, Soft-Bristled Fiber Brush Mild Detergent, Non-Abrasive Cleanser Clean Soft Cloth / Sponge... - Page 14 EXPLODED VIEW: MODEL B406 Model: B406 Built-in Electric Charbroiler PL162 IL1731 Rev. A 4/15/09...
- Page 15 PARTS LIST: B406 B406 Electric Charbroiler Fig No Part No Description WS-21707 BROILER GRATE B40 / B406 H6-32728 COVER RR ELEM ASSY B40 / B406 WS-57509 CASTING ASSY ELEM REAR 2P-32428 SPRING SUPPORT ROD 2A-32729 ROD HEAD SUPPORT B40 / B406 H6-35594 PAN GREASE B40 2A-32840...
- Page 16 EXPLODED VIEW: MODEL B446 Model: B446 Built-in Electric Charbroiler PL162 IL1732 Rev. A 4/16/09...
- Page 17 PARTS LIST: MODEL 446 B446 Electric Charbroiler Fig No Part No Description H6-38623 GRATE MACH BROILER ASSY H6-32740 COVER RR ELEM ASSY WS-57507 CASTING ASSY ELEM REAR 2P-32428 SPRING SUPPORT ROD 2A-34061 ROD HEAD SUPPORT H6-35593 PAN GREASE B44-50 2A-32840 PIVOT BRKT LF SIDE B40 2A-32841 PIVOT BRKT RT SIDE B40...
- Page 18 EXPLODED VIEW: MODEL B506 Model: B506 Built-in Electric Charbroiler PL162 IL1733 Rev. A 4/16/09...
- Page 19 PARTS LIST: MODEL B506 B506 Electric Charbroiler Fig No Part No Description H6-38623 GRATE MACH BROILER ASSY H6-32740 COVER RR ELEMENT WS-57507 CASTING ASSY, ELEMENT REAR 2P-32428 SPRING, SUPPORT ROD 2A-32741 ROD, HEAD SUPPORT ASSY H6-35593 PAN GREASE 2A-32840 PIVOT BRKT LF SIDE WS-57779 CONTACTOR 3POLE 208V 40A WS-57780...
-
Page 20: Wiring Diagram
WIRING DIAGRAM: B406... - Page 21 WIRING DIAGRAM: B446...
-
Page 22: Wiring Diagram
WIRING DIAGRAM: B506... -
Page 23: Parts & Service
H6-35593 filters. For factory authorized GREASE PAN, B-406 H6-35594 service, or to order factory authorized replacement parts, contact your Wells authorized GRATE, B-446 (1 PER UNIT) service agency, or call: B-506 (2 PER UNIT) 2F-30025 Wells Bloomfield, LLC GRATE, B-406... - Page 24 WELLS BLOOMFIELD, LLC 10 Sunnen Dr., St. Louis, MO 63143 telephone: 314-678-6314 fax: 314-781-2714 www.wells-mfg.com...
