Summary of Contents for Vantec UGT-FW050
- Page 1 4-Port FireWire 400 PCI Host Card User Manual Model: UGT-FW050 All brand names and trademarks are properties of their respective owners. w w w . v a n t e c u s a . c o m...
-
Page 2: Features And Benefits
Features and Benefits VIA VT6306 chipset PCI 32-bit 33MHz Interface Compliant IEEE 1394-1995, 1394a (rev. 1.1) and OHCI Interface Specification 1.0 Supports data transfer rates of 100, 200 and 400 Mbps Hot-swapping features allows you to connect/disconnect devices without powering down your system Adds four IEEE 1394a (FireWire 400) ports to your PC for high-speed I/O connectivity and support up to 63 devices One (1) internal IEEE 1394a port (Sharing with first external... -
Page 3: Package Contents
Package Contents 1 x 4-Port FireWire 400 PCI Host Card Adapter 1 x User’s Manual 1 x 1394a DV Cable (6-pin to 4-pin) Hardware Description Before installing the 4-Port FireWire 400 PCI Host Card, please see the photo below highlighting the available IEEE 1394aports of the card. -
Page 4: Hardware Installation
same time. Hardware Installation Turn Off the power to your computer. Unplug the power cord and remove your computer’s cover. Remove the slot bracket from an available PCI slot. To install the card, carefully align the card’s bus connector with the selected PCI slot on the motherboard. Push the board down firmly.
