Vantec EZ-Swap MRK-103F Quick Installation Manual

Download this manual

Model MRK-103F

1. Front Panel Description

2. Function Settings and Operation

2-1 Power Indicator and HDD Access indicator

When power is turned on, the indicator will displays the following

Item

Power Indicator

HDD Access Indicator

2-2 Key lock

3. Installing Hard Drive into Cartridge

Step 1

1-1. Pull the active-handle outwards and use the miniature key provided and insert into the key hole,

turning the key anti-clockwise, then the handle will auto-eject for pulling out. (Fig.1)

http://www.vantecusa.com

1. HDD Access indicator

2. Power indicator

3. Active-handle

4. Handle

5. Cartridge frame

6. Key lock

Indicator

Green LED

Amber LED

Status

Power status

Segment

OFF

EZ•Swap Quick Installation Guide

Security status

Locked (Irremovable)

Unlocked (Removable)

Fig. 1

Need help?

Do you have a question about the EZ-Swap MRK-103F and is the answer not in the manual?

Page 1 1-1. Pull the active-handle outwards and use the miniature key provided and insert into the key hole, turning the key anti-clockwise, then the handle will auto-eject for pulling out. (Fig.1) Fig. 1 Copyright 2002 Vantec Thermal Technologies, INC. All Rights Reserved http://www.vantecusa.com...
Page 2 3-2. Position the HDD into carrier body and secure the HDD using the four 6#-32 screws provided. (Fig.5) Fig. 5 Step 4 4-1. Slide the top cover back to the carrier body by sliding forward to secure. (Fig.6) Fig. 6 Copyright 2002 Vantec Thermal Technologies, INC. All Rights Reserved http://www.vantecusa.com...
Page 3 6-2. Pull the active-handle outwards and use the miniature key provided and insert into the key hole, turning the key clockwise to secure the handle. (Refer to section 2-2 Key lock) Copyright 2002 Vantec Thermal Technologies, INC. All Rights Reserved...
