Vantec NexStar Dual Bay Hard Drive Dock NST-D200SU User Manual

Dual bay hard drive dock
Hide thumbs
Table of Contents

Advertisement

Quick Links

User's Manual
Model : NST-D200 SU
www.vantecusa.com
SATA to eSATA & USB 2.0
All Registered Trademarks Belong To Their Respected Companies.
Copyright © 2008 Vantec Thermal Technologies. All Rights Reserved.

Advertisement

Table of Contents
loading

Related Manuals for Vantec NexStar Dual Bay Hard Drive Dock NST-D200SU

Summary of Contents for Vantec NexStar Dual Bay Hard Drive Dock NST-D200SU

  • Page 1 User’s Manual Model : NST-D200 SU www.vantecusa.com SATA to eSATA & USB 2.0 All Registered Trademarks Belong To Their Respected Companies. Copyright © 2008 Vantec Thermal Technologies. All Rights Reserved.

  • Page 2: Table Of Contents

    Table of Contents 1.Introduction ..1 2.System Requirements ... 1 Features/Specifications 4.Installation ... 4 5.Removal ... 7 6.Driver Installation ... 9 Windows 2000/XP/VISTA ... 9 Windows ME ..9 Mac OS 9.0 or later ... 10 Mac OS 8.6 ... 10 7.

  • Page 3: Introduction

    1.Introduct The Vantec NexStar Dual Bay Hard Drive Dock is a complete and easy way to add or swap hard drives to your computer. It gives you the flexibility of connecting two SATA I/II hard drive to your computer via USB 2.0 or eSATA connection without opening up your computer case or installing into an enclosure.

  • Page 4: Features/Specifications

    3.Features/Specifications Features ： ■ Install and Access Hard Drives in Seconds ■ Simple to Use Design ■ Eject Button for Easy Removal of Hard Drive ■ Supports two 2.5"/3.5" SATA I/II Hard Drive up to 3 TB ■ Add Storage to Any System with USB or eSATA ■...

  • Page 5: Specifications

    Specifications ： ■ Model ：NST-D200SU ■ Device Support ：SATA I/II Hard Drive ■ Device Size ：2.5”or 3.5” ■ Internal Interface ：SATA ■ External Interface ：USB 2.0 & eSATA ■ Material ：Plastic ■ Dimension ：140 x 118 x 88 mm ■ HDD Capacity ：Up to 2TB ■...

  • Page 6: Installation

    4.Installation 1. Connect the power adapter to the NexStar Dual Bay Hard Drive Dock. 2. Connect the USB or eSATA Cable to the NexStar Dual Bay Hard Drive Dock and attach the other end to your computer. Note: For eSATA connections, the system must support Port Multiplier (PM) specifications to read both hard drives.
  • Page 7 3. Insert 2.5” or 3.5” SATA HDD into the slot.
  • Page 8 3-1. When the eject button is upright, the NexStar Dual Bay Hard Drive Dock is ready for use.

  • Page 9: Removal

    5.Removal Push down the button to eject the HDD. (Stablize the HDD with your hard). Warning: Please power down the Hard Drive Dock by pressing the power button to ensure safe removal of the hard drive(s). Do not remove the hard drive(s) when the disc is reading or writing.
  • Page 10 3. Remove the HDD from the Hard Drive Dock.

  • Page 11: Driver Installation

    6.Driver Installation Windows 2000/XP/VISTA No drivers are necessary when using Windows 2000/XP/VISTA. If the hard drive does not appear under My Computer, be sure to enter disc management in your control panel to partition your hard drive. Windows ME 1. The first time you plug in the NexStar Dual Bay Hard Drive Dock into a USB port of your computer, the "Add New Hardware Wizard"...

  • Page 12: Mac Os 9.0 Or Later

    Mac OS 9.0 or later No drivers are necessary when using Mac OS 9.0 above. If the hard drive does not appear on the desktop, be sure to partition your hard drive. Mac OS 8.6 1. Unplug the NexStar Dual Bay Hard Drive Dock if you currently have it connected. 2.

  • Page 13: Warranty

    If any parts are missing or if there are cosmetic defects, please contact the retailer from which you purchased the unit immediately and ask for a replacement. Vantec Thermal Technologies 43951 Boscell Rd. Fremont, CA 94538 tel: 510-668-0368 fax: 510-668-0367...
