Option 2: PoE Injector
KP-4000
1. Connect the CAT 5 cable (RJ45) to the LAN connection on the
rear of the KP-4000.
2. Plug the other end of the CAT 5 cable to the PoE Injector which
will power the KP-4000.
3. Connect the PoE injector (not included) to the Router.
Option 3: No PoE: 12 Volt Power Supply
Router
1. Splice a 12V 1Amp Power Adapter (not included) and connect to
the rear Power input.
2. For network connections to IP devices, MRX-1 and the internet,
connect a CAT 5 cable (RJ-45) to the LAN connection on the rear
of the KP-4000 and plug the other end into the Router.
KP-4000 N
ETWORK
PoE Injector
(not included)
KP-4000
Page 4
K
EYPAD
Power Supply
(not included)
Router
